Overview
The Sanyo Denki 103G770-2516 is a brushless stepping motor engineered for precision positioning and motion control in industrial automation applications. This flange-mounted unit delivers consistent 1.8° step angles (200 steps per revolution) and operates on DC current, making it suitable for equipment requiring accurate, repeatable angular increments. Manufactured in Japan, this Step Syn motor is built to deliver reliable performance across diverse automation environments.
Key Features
- 1.8° full step angle with 200 steps per revolution for precise positioning
- Compact flange-mount design for straightforward mechanical integration
- Splined shaft type for secure drive coupling
- DC current operation with 4.1V nominal rated input voltage
- Insulation Class B rated for operating temperatures up to 266°F (130°C)
- Full load current rating of 1.1A for efficient power consumption
Technical Specifications
The motor combines reliable stepper motor performance with straightforward electrical requirements, making it an excellent fit for retrofit and new automation projects.
Typical Applications
- Industrial positioning and indexing systems
- Automation machinery requiring precise angular control
- Printing and paper handling equipment
- Medical and laboratory instrumentation
- Optical scanning and alignment systems
- General-purpose motion control where step resolution is critical
Compatibility & Replacements
Compatible With
- Standard stepper motor drivers and controllers supporting 4.1V DC unipolar or bipolar operation
- Industrial control systems using stepping motor logic
- Retrofit applications in legacy automation equipment
- Custom motion control boards and embedded systems
Replaces / Drop-In Replacement For
The 103G770-2516 is part of the Sanyo Denki Step Syn 103G770 series. Related models within this series include the 103G770-2521 and other 103G770 variants. For exact drop-in compatibility with your existing equipment, verify the shaft type, flange dimensions, and electrical requirements with your system integrator before ordering.
Works With
- DC stepper motor drivers and microcontroller interfaces
- Unipolar and bipolar stepper control circuits
- Industrial PLCs supporting stepper motor outputs
- Custom automation solutions requiring precise incremental motion
- Legacy industrial equipment using Sanyo Denki stepping motors
