Overview
The Ricoh FL-CC7528-2M is a fixed focal-length machine vision lens engineered for 2-megapixel imaging applications in factory automation, robotics, and precision measurement. With a 75mm focal length, F2.8 aperture, and C-mount interface, this lens provides exceptional optical performance for medium-distance inspection tasks requiring high resolution and contrast. Built with a robust metal housing and precision manual controls, the FL-CC7528-2M is a reliable choice for OEM integration and system upgrades.
Key Features
- Fixed 75mm focal length — optimized for mid-range imaging applications
- Manual iris and focus — locking screws for stable, repeatable positioning
- High transmission coating — maximizes light throughput and image contrast
- 2/3″ format, 2MP rated — compatible with standard machine vision cameras
- C-mount interface — direct compatibility with industrial and embedded vision systems
- Compact metal construction — durable and thermally stable for long-term field use
Technical Specifications
- Focal Length: 75 mm (fixed)
- Aperture Range (F): 2.8–32
- Mount Type: C-Mount
- Image Circle / Format: 2/3″
- Minimal Object Distance (M.O.D.): 0.7 m
- Back Focal Length: 30.94 mm
- Immersion Depth: 4.0 mm
- Angle of View (H×V): 6.9° × 5.2°
- Iris Type: Manual, locking mechanism
- Focus Type: Manual, locking mechanism
- Megapixel Rating: 2 MP
- Housing Material: Metal
- Origin: Made in Japan
Typical Applications
The Ricoh FL-CC7528-2M is ideal for:
- High-resolution quality inspection and defect detection
- Precision measurement and dimensional verification
- Machine vision-guided robotics and positioning systems
- Factory automation and in-line monitoring
- Medical device and pharmaceutical packaging inspection
- Semiconductor and electronics assembly verification
Compatibility & Replacements
Compatible With
- Standard C-mount machine vision cameras and industrial embedded systems
- 2-megapixel and lower-resolution imaging sensors
- Industrial vision platforms: JAI, Allied Vision, Basler, IDS, The Imaging Source, and others
- OEM vision integration systems and custom imaging applications
Replaces / Drop-In Replacement For
- Pentax C37500KP (legacy part number for this lens)
- Direct replacement for legacy Ricoh/Pentax 75mm F2.8 2MP machine vision lens installations
Works With
- C-mount and CS-mount compatible cameras
- Industrial vision software: HALCON, Cognex VisionPro, OpenCV, MVTec, and custom machine vision applications
- Factory automation systems using GenICam, GigE Vision, USB 3 Vision, and CoaXPress camera interfaces
- Robotics platforms: Universal Robots (UR), KUKA, ABB, Fanuc with machine vision integration
