Overview
The PHD 17000-31-5 switch bracket is a compact mounting solution designed specifically for PHD’s 1750 series pneumatic cylinders with bore size 22. This bracket is essential for proper proximity switch or reed switch installation on rotary and multi-motion actuators, providing the mechanical alignment and stability needed for consistent sensor operation in industrial automation environments.
Key Features
- Compact bracket design minimizes footprint in tight machine spaces
- Engineered for bore size 22 cylinders in the 1750 series
- Compatible with rotary and multi-motion actuators
- Precision mounting ensures accurate switch positioning and repeatability
- Durable construction for demanding industrial applications
Technical Specifications
The bracket is manufactured to OEM specifications for direct fitment with PHD cylinder actuators. Construction materials and finish are optimized for use in standard pneumatic environments with typical operating temperatures and humidity ranges common to factory floor applications.
Typical Applications
The PHD 17000-31-5 is widely used in:
- Pneumatic automation systems requiring position feedback
- Manufacturing machinery with multi-motion actuators
- Assembly line systems with proximity switch integration
- Industrial robotic applications using PHD cylinder actuation
- Process control systems with cylinder position monitoring
Compatibility & Replacements
Compatible With
- PHD 1750 series pneumatic cylinders
- Bore size 22 rotary and multi-motion actuators
- PHD rotary and multi-motion cylinder platforms
- Standard proximity switch and reed switch sensors
Replaces / Drop-In Replacement For
This part is the OEM bracket for bore size 22 cylinders in the 1750 series. Verify compatibility with your specific cylinder configuration and mounting orientation before ordering.
Works With
- PHD 1750 series pneumatic cylinders
- Multi-motion and rotary actuators
- Inductive proximity switches
- Reed switches for position feedback
- Industrial PLC and control systems
