Overview
The Omega iPTP-Probe PT06A-10-6S is a dual-function pressure and temperature sensor probe designed for industrial automation, process monitoring, and data acquisition applications. This probe combines reliable measurement capability with a rugged MIL-spec connectorized cable assembly, making it suitable for field deployment in manufacturing and control environments. The unit delivers 2.2V-3.7V analog output proportional to sensed pressure and temperature conditions.
Key Features
- Pressure measurement range: 0–200 PSI
- Temperature measurement range: 0–70°C
- 2.2V–3.7V DC analog output
- 10-foot cable with PT06A-10-6S circular connector (6-position, bayonet coupling)
- Suitable for PLC, HMI, and data logging system integration
- Industrial-grade construction for harsh environments
Technical Specifications
Key performance parameters for this Omega probe assembly:
- Pressure Range: 0–200 PSI
- Temperature Range: 0–70°C
- Output Signal: 2.2–3.7 V DC
- Cable Length: 10 feet
- Connector Type: PT06A-10-6S (Amphenol MIL-C-26482 circular plug, 6-position, bayonet coupling, solder cup terminals)
- Connector Body: Aluminum alloy with olive drab chromate over cadmium plating
- Contact Material: Copper alloy
- Coupling Style: Bayonet
- Termination: Solder cup
Typical Applications
- Process pressure and temperature monitoring in manufacturing cells
- PLC-based automation systems requiring dual sensing inputs
- Industrial data acquisition and logging
- Environmental chamber and test equipment integration
- Hydraulic and pneumatic system supervision
- HVAC and thermal management monitoring
Compatibility & Replacements
Compatible With
- Allen-Bradley CompactLogix and ControlLogix analog input modules
- Siemens S7-1200, S7-1500, and ET 200 I/O systems
- Mitsubishi FX3U/FX5U PLCs with analog input cards
- Omron CJ2M and NX-series controllers
- Standard 4–20 mA or 0–10 V analog input channels
- Data loggers and multi-channel monitoring devices
Replaces / Drop-In Replacement For
Verify exact model equivalence with your system integrator or Omega product support before ordering. PT06A-10-6S connector compatibility with existing probe installations should be confirmed.
Works With
- Studio 5000 and RSLogix 5000 analog scaling
- TIA Portal analog input configuration
- GX Works2 and GX Works3 parameter setup
- Omron Sysmac Studio analog modules
- EtherNet/IP and PROFINET gateways with analog-to-digital conversion
- Third-party DAQ software supporting 0–10 V or 2–3.7 V sensors
