Overview
The Numatics 139-329P solenoid coil is a proven industrial solenoid valve coil designed for pneumatic and fluid control systems. This dual-voltage Decco-series component operates at 110-120 VAC (60 Hz) or 100-115 VAC (50 Hz), making it suitable for both North American and international installations. With a simple 2-wire lead design and industry-standard MK10 mounting, the 139-329P integrates seamlessly into existing valve assemblies and automation platforms.
Key Features
- Dual-voltage operation: 110-120 VAC (60 Hz) / 100-115 VAC (50 Hz)
- 2-wire lead configuration for straightforward wiring and installation
- MK10 mounting interface for direct valve integration
- Compact 3-inch form factor reduces panel space requirements
- Lightweight design (approx. 0.14 lbs) for portable and modular systems
- Proven Numatics Decco quality—established OEM and aftermarket standard
Technical Specifications
- Part Number: 139-329P (also: 139-329, 139329)
- Manufacturer: Numatics (ASCO)
- Product Type: Solenoid Valve Coil
- Voltage (Primary): 110-120 VAC, 60 Hz
- Voltage (Secondary): 100-115 VAC, 50 Hz
- Wiring: 2-wire lead
- Mounting: MK10
- Physical Length: 3 inches
- Weight: 0.14 lbs
- Color: Red (standard Decco)
Typical Applications
- Pneumatic valve actuation in manufacturing and assembly lines
- Fluid control systems for industrial process automation
- Directional control valve coils in mobile and stationary equipment
- Automation retrofit projects requiring drop-in coil replacement
- International systems requiring dual 50/60 Hz voltage compatibility
Compatibility & Replacements
Compatible With
- Numatics solenoid valve bodies with MK10 mounting interface
- ASCO pneumatic and fluid control valves (Numatics product line)
- Standard 110-120 VAC, 50-60 Hz industrial electrical systems
- Automation systems requiring 2-wire solenoid coil actuation
Replaces / Drop-In Replacement For
- Numatics 139-329 (non-P variant)
- Original equipment solenoid coils on Numatics MK10-mount valve bodies
Works With
- ASCO/Numatics pneumatic valve platforms
- Standard industrial 120 VAC control circuits and relay logic
- PLC and motion control systems with 2-wire solenoid outputs
- Both 50 Hz (Europe, Asia) and 60 Hz (North America) power systems
