Overview
The Murata EKEM12UE is a comprehensive sample kit featuring chip EMI filters from Murata’s NFM, NFR, NFW, and NFE series. EMIFIL products are LC low-pass filters combining capacitors and inductors to produce superior insertion loss characteristics compared to single-component solutions. This sample kit enables rapid design evaluation for electromagnetic interference (EMI) suppression in industrial, consumer, and automotive applications.
Key Features
- Multiple filter case sizes for flexible circuit integration
- Assorted NFM, NFR, NFW, and NFE series filters in single kit
- Ideal for rapid prototyping and design validation
- Compact chip format for space-constrained applications
- Proven Murata EMI suppression technology across diverse markets
Technical Specifications
| Product Type | Chip EMI Filter Sample Kit |
| Manufacturer | Murata Manufacturing Co., Ltd. |
| Part Number | EKEM12UE |
| Series | NFM/NFR/NFW/NFE (EMIFIL) |
| Filter Type | LC Low-Pass Filter (Capacitor + Inductor) |
| Package Format | Chip (SMD/SMT) |
| Application Class | Power supply and signal circuits |
| RoHS Compliant | Yes |
| Operating Ambient | –40 to +125°C (typical) |
Typical Applications
- Power supply line filtering and noise suppression
- Signal circuit EMI mitigation
- DC line noise reduction in industrial equipment
- Consumer electronics and automotive noise filtering
- Design prototyping and component evaluation
