Overview
The Modicon AS-8534-000 connector is a low-density terminal connector engineered for legacy Modicon 800 Series discrete I/O modules. Originally manufactured by Gould/AEG and now supported through Schneider Electric channels, this connector provides a robust, field-proven interface for wiring industrial control systems. Each unit features 20 terminals and meets the electrical specifications required for 800 Series module compatibility.
Key Features
- 20-terminal low-density design for simplified panel wiring
- 300V / 10A continuous current rating
- Designed specifically for Modicon 800 Series I/O module integration
- Legacy-compatible with original AEG/Gould Modicon systems
- Lot of 2 units for redundancy and system maintenance
Technical Specifications
- Terminal Count: 20
- Voltage Rating: 300V AC/DC
- Current Rating: 10A continuous
- Connector Type: Low-density terminal block
- Manufacturer: Modicon (Gould/AEG)
- Compatible Series: 800 Series I/O modules
- Quantity: 2 units per lot
- Condition: New in Box
Typical Applications
The Modicon AS-8534-000 is commonly used in legacy automation systems for:
- Discrete AC/DC input module wiring (115VAC, 230VAC, 24VDC modules)
- Industrial control panel I/O termination
- Modicon 800 Series PLC rack installations
- System upgrades and maintenance replacements
- Retrofit projects maintaining original hardware compatibility
Compatibility & Replacements
Compatible With
- Modicon 800 Series discrete I/O modules (AS-B8XX series)
- Modicon 800 Series input modules (115VAC, 230VAC, 24VDC)
- Modicon 800 Series output modules
- Gould/AEG legacy PLC systems
- Industrial control panels using Modicon I/O architecture
Replaces / Drop-In Replacement For
- Modicon AS-8534-000 original equipment
- Worn or damaged low-density connectors in 800 Series systems
- Original Gould AEG connector assemblies
Works With
- Modicon 984 series processors with 800 Series I/O racks
- Legacy industrial control systems requiring terminal-based I/O wiring
- Original AEG/Gould documentation and installation guides
