Overview
The Turck U2-10922 NG/BSM 5-TR is a terminating resistor connector engineered for use in industrial fieldbus and distributed I/O networks. This 5-pin male M16 connection unit provides essential signal integrity by terminating transmission lines at network endpoints. Turck terminating resistors prevent signal reflections that degrade communication reliability, making this component critical for CANopen, DeviceNet, and other serial communication protocols in manufacturing and process control systems.
Key Features
- 5-pin M16 connector configuration for standard industrial networks
- Terminating resistor integrated into connector housing for space-efficient installation
- Quick-disconnect design enables rapid field replacement and troubleshooting
- Rated for 10–30 VDC fieldbus supply voltages
- Compact form factor suitable for cramped cabinet and panel-mount applications
- Screw-clamp termination method for secure wire connections
Technical Specifications
- Connector Type: M16 circular connector, male
- Number of Contacts: 5 pins
- Termination Method: Screw-clamp (M16 thread)
- Rated Voltage: 10–30 VDC (typical fieldbus range)
- Connector Class: Industrial-grade, IP67-compatible
- Cable Entry: M16×2 threaded gland
- Cable Size Range: 6–8 mm OD (typical for fieldbus cables)
Typical Applications
The Turck U2-10922 terminating resistor is commonly deployed in the following automation environments:
- CANopen and DeviceNet fieldbus end-node termination
- Distributed I/O and remote terminal unit (RTU) networks
- Machine tool and production line control systems
- Manufacturing execution system (MES) sensor networks
- Mobile machinery (forestry, construction) communication buses
- Process automation and batch control systems
Compatibility & Replacements
Compatible With
- Turck NG/BSM series fieldbus connectors
- CANopen, CANopen Safety, and PNOZ networks
- DeviceNet and CIP-based industrial protocols
- Turck Elektronik and murrelektronik modular I/O systems
Replaces / Drop-In Replacement For
- Earlier Turck terminating resistor models using M16 connectors
- Generic 5-pin M16 terminating resistor connectors with 120 Ω or 60 Ω configurations
Works With
- Turck TBEN, TUIS, and modular gateway systems
- PROFINET, EtherNet/IP, and open industrial networks
- Turck IO-Link sensor and actuator ecosystems
- Standard 5-pin M16 circular connector wiring harnesses
