Overview
The Mitsubishi AJ65VBTS3-16D is a compact remote I/O module engineered for CC-Link networked control systems. This unit extends digital input/output capabilities across distributed automation architectures, allowing remote sensors and actuators to connect seamlessly to MELSEC programmable controllers via the CC-Link communication protocol. The AJ65VBTS3-16D supports DC input channels with compact form factor mounting, making it ideal for space-constrained industrial environments requiring real-time I/O synchronization.
Key Features
- 16-point DC digital input module with positive common configuration
- CC-Link System communication for distributed remote I/O
- Compact module design for panel-mount installation
- Full compatibility with MELSEC-A and MELSEC iQ-F PLC series
- Input signal filtering and isolated inputs for noise immunity
- DIN rail and panel mounting options
Technical Specifications
- Module Type: CC-Link Compact Remote I/O (Digital Input)
- Input Points: 16 DC inputs
- Input Type: DC input, positive common
- Communication Protocol: CC-Link (MELSEC network)
- Operating Voltage: 24 V DC (typical supply)
- Mounting: DIN rail or panel-mount capable
- Wire Connection: Terminal block, 0.3–1.65 mm² conductor size
- Industry Standard: MELSEC compatible network module
- Certifications: Mitsubishi FA compliance
Typical Applications
- Distributed discrete I/O for large-scale manufacturing lines
- Remote sensor monitoring in multi-zone production facilities
- Machine tool networks requiring synchronized digital inputs
- Packaging and conveyor control with extended I/O reach
- Chemical or food processing plants with remote data acquisition points
- Building automation and HVAC distributed control networks
Compatibility & Replacements
Compatible With
- MELSEC-A series programmable controllers
- MELSEC iQ-F series PLCs
- CC-Link master stations and remote I/O networks
- Mitsubishi GX Works 2 and GX Works 3 software
- CC-Link gateway devices and network switches
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. Direct replacement specifications should be confirmed against your MELSEC controller model and CC-Link network configuration.
Works With
- CC-Link industrial networking protocol
- MELSEC engineering software (GX Works 2, GX Works 3)
- Mitsubishi SCADA and HMI systems
- Real-time I/O synchronization for deterministic control
- Standard DC 24 V industrial power supplies
