The McGill CF2S Cam Follower is a robust and reliable component designed for various industrial applications requiring precise motion control.
Key Features
- Full Complement Needle Roller Construction: Provides high radial load capacity and enhanced resistance to shock loading.
- Sealed Design with LUBRI-DISC® Seal: Extends bearing life by preventing metal-to-metal contact and offering a barrier against contaminants.
- Heavy Sectioned Outer Race: Withstands shock loading during cam follower operation.
- Pre-Lubricated with Lithium Soap Thickened Grease: Ensures smooth operation and reduces maintenance requirements.
- Black Oxide Finish: Provides corrosion resistance and enhances durability.
Specifications
- Roller Diameter: 2.0000 inches
- Roller Width: 1.2500 inches
- Stud Diameter: 0.8750 inches
- Stud Length: 2.0000 inches
- Thread Size: 7/8-14
- Dynamic Load Capacity: 8,090 lbs
- Static Load Capacity: 8,200 lbs
- Maximum RPM: 1,400
- Closure Type: Sealed
- Head Type: Screwdriver Slot
- Lubrication Hole Location: Stud Side
- Series: Inch CAMROL (CF)
- Finish Coating: Black Oxide
- Weight: 1.35 lbs
The McGill CF2S Cam Follower is engineered to deliver exceptional performance and longevity in demanding environments, making it a preferred choice for industries requiring precise and durable motion control solutions.
