Overview
The Magnetek Flex EX2 6EX2 is a next-generation wireless radio remote control transmitter engineered for precision control of lifting and rigging equipment. This dual-speed, six-button transmitter system delivers improved ergonomics and serviceability over the original Flex EX series while maintaining exceptional value for hoisting, overhead crane, and material handling applications.
Key Features
- IP66-Rated Enclosure: Fully sealed transmitter and receiver enclosures protect against harsh indoor and outdoor environments
- Advanced Safety Technology: Zero G feature identifies accidental transmitter drops, ceasing all operation to prevent unintended equipment motion
- Six Programmable Buttons: 2-step pushbuttons with 3 or 4 output relays per motion, plus E-stop and key rotary controls for horn and start functions
- Ergonomic Design: Rounded nylon and fiberglass composite enclosure with snap-action buttons and positive tactile feedback—operable while wearing gloves
- Extended Runtime: Two AA alkaline batteries provide more than 100 hours of operation
- Durable Contacts: Gold-plated pushbutton contacts rated for more than two million press cycles
- Flexible Programming: More than 200 programmable functions suit all types of applications
- Wireless Pairing: Replacement transmitters pair wirelessly from transmitter to transmitter or receiver to transmitter
Technical Specifications
- Transmitter Buttons: 6 (2-speed pushbutton configuration)
- Motion Control: 3-motion, 2-speed with E-stop, Off/On/Start
- Battery Type: Two AA alkaline
- Battery Runtime: More than 100 hours
- Enclosure Rating: IP66 (fully sealed)
- Pushbutton Rating: Over 2 million press cycles (gold-plated contacts)
- Transmitter Material: Industrial-strength nylon and fiberglass composite
- Receiver Voltage Options: 110-120VAC or 9-36VDC
- Encoding Method: 32-bit CRC and Hamming Code (ultra-fast, error-free)
- Unique ID Codes: Over 1 million per system (20-bit)
- IR Configuration: Built-in infrared for easy setup with IR Programmer
Typical Applications
- Overhead bridge and gantry cranes
- Material handling and hoist systems
- Mobile hydraulic equipment
- Construction and rigging operations
- Manufacturing and logistics facilities
- Any wireless control application requiring robust, multi-function remote operation in demanding environments
Compatibility & Replacements
Compatible With
- Flex EX2 receiver systems (9-36VDC and 110-120VAC models)
- First-generation Flex EX receivers (backward compatible)
- Industrial hoisting and material handling equipment from multiple manufacturers
- Systems requiring 2-speed, 3-motion control with multi-function pushbutton operation
Replaces / Drop-In Replacement For
- Original Magnetek Flex EX transmitters (via backward compatibility)
- FLEX-6EX2 transmitters requiring upgrade or repair
- Note: Verify specific compatibility with your system integrator or equipment manufacturer before ordering
Works With
- Magnetek Flex EX2 radio systems (all configurations)
- Wireless IR Programmer for transmitter configuration
- Optional accessories: protective rubber boots, padded nylon case, retractable belt clip, horn kits, and charging cradles
- Tandem function and random access multi-receiver capability
