Overview
The Lutron AY-600P-WH Ariadni dimmer is a traditional-style single pole dimmer designed for incandescent and halogen lighting loads up to 600W at 120V. This toggle dimmer combines a standard on/off switch with a slide control for smooth brightness adjustment, making it an ideal retrofit or new-installation choice for residential and light commercial environments.
Key Features
- Toggle on/off with slide dimmer: Traditional switch operation with side-mounted slide for brightness control
- Shallow 1-inch deep back cover: Simplifies installation in existing wall boxes and compatible with standard wallplates
- Power failure memory: Dimmer returns to preset brightness level after power loss
- Superior RFI suppression: Reduces radio frequency interference for clean operation
- Matches existing switches: White finish integrates seamlessly with traditional décor
- 600W incandescent/halogen rated: Full load capacity for standard lighting applications
Technical Specifications
- Voltage Rating: 120 VAC, 60 Hz
- Load Capacity: 600W incandescent/halogen
- Configuration: Single pole
- Dimming Range: 0–100% brightness (slide control)
- Back Cover Depth: 1 inch
- Finish: White
- Terminal Type: Screw-type
- Actuator Type: Toggle switch with slide control
- Material: Plastic enclosure with metal components
- Operating Temperature: 0–40°C
Typical Applications
- Residential bedroom and living area lighting control
- Retail and hospitality ambient lighting
- Hallway and accent lighting dimming
- Replacement of failed or outdated toggle dimmers
- Energy-efficient lighting retrofit installations
Compatibility & Replacements
Compatible With
- Standard US residential electrical boxes (gang-mounted)
- Traditional single-pole switch wiring configurations
- Lutron Fassada® wallplates (1-gang and multi-gang, ordered separately)
- 120V, 60 Hz AC power supplies
- Incandescent and halogen lamp fixtures
Replaces / Drop-In Replacement For
- Lutron Ariadni AY-600P models in other finishes (light almond, almond, ivory, brown, black, stainless steel)
- Older style toggle dimmers rated for 600W single-pole applications
- Standard on/off switches in single-pole configurations requiring dimming capability
Works With
- Lutron Fassada® gloss wallplates (white finish available)
- Standard 14/2 or 12/2 NM-B residential electrical wire
- Conventional incandescent and halogen light bulbs
- Verify compatibility with your specific electrical system before ordering
