Koganei 0-9bar Solenoid Air Valve 200-4E1

Overview

The Koganei 200-4E1 is a solenoid-operated air control valve designed for pneumatic applications requiring precise flow regulation at moderate pressure ranges. As part of the Koganei 200 series, this solenoid air valve delivers reliable on/off and proportional control in industrial automation systems. With a 0-9 bar (0-0.9 MPa) operating range, it is well-suited for pilot-operated actuators and small-to-medium bore cylinders in manufacturing and process control environments.

Key Features

• Operating pressure range: 0–9 bar (0–0.9 MPa)
• Single solenoid configuration for direct or indirect control
• Compact 5-port, 3-position valve design
• Flow capacity up to 1000 R/min (ANR) at rated pressure
• Manifold-mountable with direct piping options
• Solenoid coil available in AC100V, AC200V, and DC voltage variants
• Low power consumption solenoid design
• Japanese precision manufacturing for consistent performance

Technical Specifications

• Model Number: 200-4E1
• Pressure Range: 0–9 bar (0–0.9 MPa)
• Valve Type: 5-port, 3-position, single solenoid
• Flow Capacity: Up to 1000 R/min (ANR)
• Port Configuration: P (supply), A/B (work), R1/R2 (exhaust)
• Valve Position: Normally closed or normally open (configurable)
• Solenoid Control: Direct or indirect operation
• Mounting: Direct piping or manifold mounting (compatible with Koganei BM□ series manifolds)
• Coil Options: AC100V, AC200V, DC24V (see order code suffixes)
• Manufacturer: Koganei Corporation (Japan)
• Manual Override: Optional (order code -81)

Typical Applications

The Koganei 200-4E1 is commonly applied in:

• Pilot-operated cylinder control circuits
• Air-driven actuator sequencing (bore sizes 25–50 mm)
• Industrial automation control valves for processing equipment
• CNC machine tool pneumatic circuits
• Packaging and material handling automation
• Integrated valve manifold assemblies

Compatibility & Replacements

Compatible With

• Koganei BM□T, BM□L, BM□A, BM□F, BM□U manifold series
• Direct piping and manifold block integration
• Single and double solenoid configurations
• Pneumatic control systems operating 0–0.9 MPa pressure range
• Pilot-operated spool valve assemblies

Replaces / Drop-In Replacement For

Verify compatibility with your system integrator before ordering. This model may be used as a replacement for specific earlier Koganei 200-series units in comparable pilot valve applications; however, confirm mounting, solenoid voltage, and manifold compatibility with technical documentation.

Works With

• Pneumatic control logic systems (air piloted or solenoid piloted)
• Industrial PLC and motion control systems
• Manifold-integrated valve pack designs
• ISO 4401 (CETOP-05) cavity mounting (with adapters)
• AC and DC solenoid coil power supplies
