Overview
The SOLA SDN5-24-100 is an industrial-grade DIN rail-mounted DC power supply from SolaHD, designed to deliver stable 24V DC power in the most demanding automation and machinery control environments. The SDN-P series combines proven reliability with advanced protection circuitry, making it a standard choice for material handling conveyors, industrial machinery, and process control systems.
Key Features
- Sag Immunity & Transient Suppression: Sag Immunity, transient suppression and noise tolerant, the SDN series ensures compatibility in demanding applications.
- Auto-Select Input: Auto Select 115/230 Vac, 50/60 Hz Input allows flexible installation without jumper configuration.
- Power Factor Correction: Power Factor Correction (per EN61000-3-2) meets international regulatory standards.
- Adjustable Output & Parallel Operation: Adjustable Voltage and parallel capability enable flexible system design and redundancy options.
- Industrial Temperature Range: -10°C to 60°C operation without derating.
- Short Circuit & Overvoltage Protection: Indefinite short circuit, overvoltage and overtemperature protection.
Technical Specifications
- Output Voltage: 22.5 – 28.5V DC
- Output Current: 5 Amps
- Output Power: 120W
- Input Voltage: 85 – 132 / 176 – 264V AC & 90 – 375V DC
- Input Phase: 1-Phase
- Frequency: 50/60 Hz
- Mounting: DIN Rail
- Dimensions: 4.88″ x 2.56″ x 4.55″
- Series: SDN Series
- Operating Temperature: -10°C to 60°C operation without derating
Typical Applications
The SOLA SDN5-24-100 is ideal for industrial machinery control, process automation, conveying equipment, and material handling systems that require stable 24V DC power in electrically noisy environments. Its ability to handle high inrush loads without shutdown or foldback makes it suitable for solenoid-heavy applications and rapid load switching.
Compatibility & Replacements
Compatible With
- DIN rail enclosures and control panels (35mm rail mounting)
- Industrial machinery control systems requiring 24V DC
- Conveying and material handling equipment
- Process control and automation systems
- Solenoid and relay loads
- PLC and HMI systems with 24V power requirements
Replaces / Drop-In Replacement For
The SDN5-24-100P is a direct replacement for earlier SDN5-24-100 models and is compatible with legacy Sola Hevi-Duty SDN-series DIN rail installations. Verify specific model compatibility with your original equipment documentation before ordering.
Works With
- DeviceNet protocol (NEC Class 2 compliant)
- Hazardous location certified variants available
- Redundancy modules (optional SDN-P redundancy accessories)
- Parallel-capable configurations for increased capacity
- Universal AC and DC input systems
