Overview
The Hubbell 2210-142CC4S is a Type C speed responsive switch engineered for precise speed sensing and industrial control applications. This centrifugal action switch delivers consistent protection against belt slippage and equipment overspeed conditions with repeatability of ±5% of set point RPM.
Key Features
- Centrifugal action with flyweight operation for reliable speed detection
- Non-directional AC or DC contacts for flexible control configurations
- Precision snap-action contacts for fast, repeatable switching
- NEMA 4 watertight enclosure rating provides protection in industrial environments
- Flange-mounted design for easy installation on driven equipment
- Manual reset capability for safety and control flexibility
Technical Specifications
- Series: 2210 Type C
- Contact Type: Non-directional, snap-action
- Enclosure Rating: NEMA 4 (Watertight)
- Mounting: Flange-mounted
- Reset: Manual
- Contact Repeatability: ±5% of set point RPM
- Contact Configuration: N.O. (Normally Open) and N.C. (Normally Closed) available
Typical Applications
- Conveyor belt speed monitoring and slippage detection
- Motor overspeed and underspeed protection
- Rotating equipment speed supervision
- Industrial machinery control and shutdown
- Pump and blower speed monitoring
- Production line equipment synchronization
Compatibility & Replacements
Compatible With
- AC motors and drives
- DC motor control systems
- Industrial control panels and pilot devices
- Conveyor and material handling equipment
- Standard electrical switching circuits
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. Related models in the Hubbell Type C series include 2210-142CC4, 2210-142CC13, and 2210-142CC13MS, though direct substitution should be confirmed with engineering documentation.
Works With
- Manual control systems and hardwired circuits
- PLC input modules (via relay interface)
- Programmable logic controller safety circuits
- SCADA monitoring systems
- Standard pilot duty control relays
