Overview
The HTD 8M-1760 timing belt is a closed-loop synchronous belt designed for precision power transmission in industrial automation and machinery. Rated with 220 teeth and an 8mm pitch profile, this belt delivers accurate torque and speed synchronization without slip. The neoprene rubber construction with fiberglass tension members ensures durability and resistance to wear in demanding applications.
Key Features
- 220 teeth, 8mm pitch profile for precision synchronization
- Neoprene rubber with fiberglass reinforced core for durability
- 1760mm pitch length (69.29 inches effective length)
- Low-noise, maintenance-free operation at variable speeds
- Compatible with standard HTD pulley systems
Technical Specifications
- Pitch: 8mm (0.315 inches)
- Pitch Length: 1760mm (69.29 inches)
- Number of Teeth: 220
- Belt Height: 6.0mm (0.236 inches)
- Tooth Height: 3.36–3.38mm (0.132–0.134 inches)
- Material: Neoprene rubber (CR) with fiberglass cord
- Standard Width Options: 15mm, 18mm, 20mm, 25mm, 30mm, 35mm, 40mm, 45mm, 50mm, 55mm, 60mm+
- Tensile Strength: ≥300 N/mm (typical)
- Reference Tension: 240 N/mm
- Elongation: ≤4%
- Hardness: 75±5 Shore A
Typical Applications
HTD 8M-1760 belts are suited for compact-drive transmission systems found across industries:
- Office equipment (copiers, printers, scanners)
- Small appliances and household machinery
- Textile machines and looms
- Machine tools and CNC equipment
- Conveyor systems and material handling
- HVAC and refrigeration units
- Automation and robotics
Compatibility & Replacements
Compatible With
- Standard HTD 8M pulley systems
- Industrial synchronous drive configurations
- OEM equipment using 8mm HTD profile belts
- Custom drive systems designed for 220-tooth HTD belts
Replaces / Drop-In Replacement For
- HTD 1760-8M (alternate designation)
- Standard 1760-8M timing belt configurations
- OEM and aftermarket HTD 8M-1760 variants from manufacturers including Bando, ContiTech, and equivalent suppliers
Works With
- HTD 8M pulley wheels (standard bore and hub styles)
- Idler and tensioner assemblies rated for 8mm pitch
- Motor and gearbox coupling systems using synchronous drive
- Industrial automation control systems requiring precision torque transmission
