Overview
The Honeywell BZE6-2RQ2 is a MICRO SWITCH E6 Series medium-duty limit switch engineered for reliable position monitoring and equipment control in industrial environments. This SPDT side-mount switch features 1NO/1NC contacts, a 6PA1 top roller actuator and screw terminations. Rated for maximum 15 amps at 125–600V AC and 125–250V DC, the BZE6-2RQ2 delivers dependable snap-action switching in compact form.
Key Features
- Single-pole double-throw (SPDT) configuration with 1NO/1NC contacts and side-mount, medium-duty sealed enclosure
- Electrostatic applied epoxy coating to zinc housings enhances durability in challenging environments
- Sealed design (with boot) preferred for applications with exposure to liquid and/or particulate environments
- Compact size permits installation where space is limited on equipment
- Incorporates the reliable snap-spring mechanism for consistent, repeatable switching action
- UL/CSA/CE approvals for regulatory compliance
Technical Specifications
- Contact Configuration: SPDT (1NO/1NC)
- Maximum Current Rating: 15 A
- AC Voltage Rating: 125–600V
- DC Voltage Rating: 125–250V
- Operating Temperature: −32 to 71 °C (−25.6 to 160 °F)
- Actuator: 6PA1 top roller arm
- Mounting: Side mounting with 25 mm mounting holes
- Sealing: IP66 (with boot seal)
- Housing: Metal with epoxy coating
- Termination: Screw terminals
- Certifications: UL Listed, CSA Certified, CE approved
Typical Applications
MICRO SWITCH E6/V6 Series medium-duty limit switches are designed for a wide variety of indoor and outdoor applications including equipment for commercial, industrial, transportation, and agriculture industries. The BZE6-2RQ2 is well-suited for conveyor systems, packaging machinery, assembly equipment, automated doors, material handling, and any application requiring position sensing with sealed enclosure protection against moisture and contaminants.
Compatibility & Replacements
Compatible With
- PLC and automation controllers with 24 VDC or 120/240 VAC control circuits
- Industrial machinery and equipment requiring position monitoring
- Conveyor systems and packaging line equipment
- Automated gate and door control systems
- Material handling and sorting applications
Replaces / Drop-In Replacement For
- BZE6-2RQ2-S (sealed variant of same model)
- Other MICRO SWITCH E6 Series SPDT switches with compatible pin layout and voltage rating
Works With
- Standard 24 VDC, 120 VAC, 240 VAC, 480 VAC industrial control circuits
- Relay logic and hardwired control systems
- PLC input modules with general-purpose dry contact sensing
- Safety circuits and permissive interlocks
