Overview
The Honeywell 060-2445-02 is a Model 13 Series subminiature load cell engineered for demanding measurement applications where space is limited. With a 500 lbs load range and non-amplified mV/V output, this unit delivers accurate force and weight sensing in compact, integrated platforms. The cell features integral twisted Teflon® leads and a balance board, making it ready for direct integration into data acquisition systems and control loops.
Key Features
- 500 lbs full-scale capacity with high repeatability and low hysteresis
- Non-amplified mV/V output—direct strain gauge signal for analog conditioning
- Compact subminiature design ideal for space-constrained installations
- Integral Teflon® shielded leads with balance board and 1.5 m (5 ft) cable
- Radial electrical exit orientation for flexible mounting and routing
- Temperature compensation range: 15°C to 70°C [60°F to 160°F]
Technical Specifications
Load range, stainless steel construction, and strain gauge technology ensure durability and accuracy in industrial environments. The mV/V sensitivity of 2.0428 mV/V provides stable, repeatable output suitable for most analog input modules and signal conditioning hardware. Teflon insulation resists moisture, oils, and many process chemicals common in automotive, packaging, chemical, and materials testing labs.
Typical Applications
- Materials testing and compression/tension measurement systems
- Weight and mass determination in process scales and hoppers
- Precision force monitoring in automated assembly equipment
- Load verification in hydraulic and pneumatic systems
- Embedded sensing in compact conveyor and handling systems
- Laboratory and calibration workstations
Compatibility & Replacements
Compatible With
- Analog signal conditioners and amplifiers accepting mV/V input
- Industrial controllers and PLCs with 4–20 mA or ±10 VDC analog input modules
- Data acquisition systems and strain gauge signal analyzers
- Weighing indicators and process scales using strain gauge inputs
- Honeywell and third-party load cell signal conditioning boxes
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. Other Honeywell Model 13 500 lbs variants may be interchangeable depending on electrical connector type and cable configuration.
Works With
- Strain gauge data acquisition cards (NI, Keysight, etc.)
- Industrial signal conditioners (Analog Devices, Phoenix Contact, Mantracourt)
- Allen-Bradley, Siemens, Mitsubishi, and Omron analog input modules
- Custom load measurement software and SCADA platforms
