Overview
The Dodge HE60X4-7/16-KW bushing (model 206688) is a high-quality taper-lock bushing designed for mechanical power transmission applications. Manufactured to industry standards, this HE series bushing provides reliable shaft-to-sprocket or shaft-to-pulley coupling in conveyor systems, gearbox assemblies, and industrial drive equipment. The precision-engineered design ensures consistent performance and long operational life in demanding industrial environments.
Key Features
- Taper-lock design for secure, repeatable shaft coupling
- Precision-manufactured to industry standards for reliability
- Suitable for conveyor and mechanical drive applications
- New in box condition—ready for immediate installation
- Dodge brand reputation for durability in power transmission
Technical Specifications
- Manufacturer: Dodge (ABB/Baldor Division)
- Model Number: 206688
- Series: HE60
- Bore Diameter: 4-7/16 inches
- Bushing Type: Taper-lock, HE series
- Application: Mechanical power transmission, conveyor systems
- Condition: New in box
- Industry Standards: Manufactured to precision industry standards
Typical Applications
- Conveyor belt drive systems
- Industrial machinery shaft couplings
- Sprocket and pulley assemblies
- Gearbox and motor drive connections
- Material handling equipment
- Mining and aggregate processing equipment
Compatibility & Replacements
Compatible With
- Dodge mechanical power transmission systems
- Standard taper-lock sprockets and pulleys
- Industrial conveyor equipment using HE series bushings
- Motor and gearbox drive trains rated for HE60 bore size
Replaces / Drop-In Replacement For
The HE60X4-7/16-KW is a direct replacement for equivalent Dodge HE60 bushings with matching bore diameter (4-7/16″) and flange configuration. Verify compatibility with your system integrator or equipment manufacturer before ordering to ensure proper fit and performance.
Works With
- Standard 4-7/16″ shaft diameters
- Dodge and compatible OEM sprockets, pulleys, and sheaves
- Industrial drive and conveyor equipment requiring taper-lock bushings
