Overview
The Dodge HE40X3-7/16-KW bushing (model 206654) is a heavy-duty taper-lock bushing designed for industrial mechanical power transmission systems. This new in box unit is engineered for conveyor systems, belt drives, and direct shaft mounting applications where precision fit and secure torque transmission are critical. The HE40 size delivers reliable performance in demanding industrial environments.
Key Features
- Taper-lock design eliminates bushing slippage and provides secure, precision fit on shafts
- Heavy-duty ductile cast iron construction rated for industrial mechanical drive duty
- 3-7/16 inch bore diameter for standard shaft applications
- KW keyway configuration for positive drive engagement
- Drop-in replacement for existing Dodge HE40 installations
- New in box condition with manufacturer quality assurance
Technical Specifications
- Manufacturer: Dodge (part of Baldor Electric/ABB group)
- Part Number: 206654
- Model: HE40X3-7/16-KW
- Bushing Type: Taper-Lock, HE series
- Bore Diameter: 3-7/16 inches
- Keyway: KW (metric conversion keyway)
- Material: Ductile Cast Iron
- Taper Angle: 8 degrees (standard Dodge taper-lock)
- Condition: New in Box
- Made in: United States
Typical Applications
- Conveyor belt drive systems
- Motor and pump shaft connections
- Fan and blower coupling applications
- Industrial gearbox input/output shafts
- Belt-driven machinery in manufacturing plants
- Heavy-duty mechanical power transmission systems
Compatibility & Replacements
Compatible With
- Dodge mechanical drive components and systems
- Standard industrial motor shafts (3-7/16″ bore applications)
- Conveyor drive pulleys and sprockets
- Baldor/ABB power transmission equipment
- Industrial automation and material handling systems
Replaces / Drop-In Replacement For
- Direct replacement for Dodge 206654 bushing applications
- Compatible with other HE40X3-7/16 taper-lock installations
- Verify bore and keyway specifications match your hub before ordering
Works With
- Dodge/Baldor taper-lock hubs (all sizes with 3-7/16″ bore)
- Standard industrial shafts with KW keyway configuration
- ANSI-standard belt pulleys and sprockets
- Direct-mount coupling systems
