Overview
Harting 09300101421 is a top entry hood designed specifically for Han 10B connectors with double-lever locking mechanisms. The hood is made of gray RAL 7037 aluminum die-cast with powder-coated surface. This connector accessory is engineered for industrial environments requiring IP65 protection and reliable environmental sealing.
Key Features
- Polycarbonate/stainless steel double locking lever with NBR seal
- Top cable entry (PG 16) with UL94V-0 flammability-rated locking lever
- NEMA type 4/4X/12 protection class and IP65 protection rating
- Operating temperature range of -40 to 125°C
- 180° cable exit angle
- Suitable for use with the Han® B series
Technical Specifications
- Connector Size: 10B (rectangular)
- Product Range: Han B Series
- Body Material: Gray RAL 7037 aluminum die-cast, powder-coated
- Locking Mechanism: Double locking lever (polycarbonate/stainless steel)
- Seal Material: NBR
- Cable Gland: PG 16
- Protection Rating: IP65
- NEMA Rating: Type 4/4X/12
- Temperature Range: -40 to 125°C
- Cable Exit Angle: 180°
- Locking Type: 2 Lever
- Hood Type: Top Entry
Typical Applications
Harting Heavy Duty Power Connectors are ideal for industrial applications with harsh requirements and help provide solutions for the wide range of needs in industrial connectors in mechanical and plant engineering. They are also used in the design and construction of equipment, in medical technology and construction machines. The HAN 10B hood is commonly deployed in automation systems, control cabinets, and field equipment requiring sealed cable entries and vibration resistance.
Compatibility & Replacements
Compatible With
- Han 10B connectors with double lever
- Han B Series inserts and contacts
- Male and female HAN connectors (size 10B)
- M25 or PG 16 cable gland systems
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. This hood is a direct match for Han 10B double-lever connector assemblies with the same cable entry configuration.
Works With
- Han B Series connectors and inserts
- Harting male and female connector contacts
- Standard industrial connector tooling and cable glands
- IP65-rated enclosure designs requiring sealed cable management
