Overview
The Habasit MVT-6P 35MMx3670MM machine tape belt is engineered for demanding material handling and paper processing applications. This flat belt combines durable polyurethane cross-linked (PUR) construction with a polyamide (PA) traction layer, delivering consistent performance across folding, paper converting, and processing operations. The belt’s non-marking surface and adhesive-free joint design minimize maintenance while ensuring smooth operation in multiple conveying orientations.
Key Features
- Abrasion-Resistant Conveying Surface: PUR cross-linked material resists wear and extends belt life in high-contact applications
- Adhesive-Free Joint Design: Eliminates adhesive degradation concerns and ensures consistent splice strength over time
- Constant Grip & Release Properties: Maintains reliable product control and release without slipping or material marking
- Dimensionally Stable: Polyamide and TPU traction layers resist stretching and maintain precise tension under load
- Non-Marking Surface: Impregnated fabric conveying side prevents surface contamination of sensitive materials
- Versatile Orientation: Rated for horizontal, inclined, and vertical conveying paths
Technical Specifications
- Belt Width: 35 mm
- Belt Length: 3670 mm
- Overall Thickness: 1.5 mm
- Conveying Side Material: Polyurethane cross-linked (PUR)
- Conveying Side Surface: Impregnated fabric, non-adhesive
- Traction Layer: Polyamide (PA) fabric / Thermoplastic polyurethane (TPU) foil
- Number of Fabric Layers: 2
- Running/Pulley Side Material: Acrylonitrile-Butadiene-Rubber (NBR)
- Running/Pulley Side Surface: Fine textile structure, adhesive rubber
- Belt Color: Black
- Conveying Modes: Horizontal, Inclined, Vertical
- Storage Conditions: Cool, dry location; protect from UV radiation and direct sunlight
Typical Applications
The MVT-6P machine tape is widely used across:
- Paper manufacturing and processing equipment
- Paper converting and printing finishing operations
- Folder belts for binding and sorting systems
- Material handling systems requiring gentle, non-marking conveying
- Processing applications in textile and converting industries where dimensional stability is critical
Compatibility & Replacements
Compatible With
- Standard conveyor systems with flat belt pulleys and roller configurations
- Paper processing and converting machinery (folder belts, processing systems)
- Material handling systems rated for polyurethane belt operation
- Applications requiring NBR-backed flat belts for grip and release control
Replaces / Drop-In Replacement For
- Direct replacement for OEM and aftermarket MVT-6P specifications
- Equivalent to ZMVT-6P where cross-reference compatibility is specified
- Verify exact system compatibility with your equipment documentation before ordering
Works With
- Flat belt pulley systems (standard groove and sleeve designs)
- Conveyor frames with horizontal, inclined, and vertical mounting configurations
- Standard belt tensioning and drive systems compatible with 35mm width belts
- Systems requiring adhesive-free, dimensionally stable belt joints
