Overview
The Gates 9389-2085 2/5VX850 Super HC Powerband Belt is a two-strand banded V-belt engineered for multi-belt drive systems requiring consistent load distribution and shock load resistance. The PowerBand construction allows multiple belts to function as one belt, with even load distribution and each strand fitting securely in the sheave groove. This 5VX section belt features a 1.2500 in top width, 85 in outside length, 0.5469 in height, and is constructed with polyester reinforcing cord. Patented ethylene material provides -60°F to +250°F temperature range to resist belt cracking.
Key Features
- Recommended for multiple V-belt drives exposed to pulsating or heavy shock loads which can make belts whip, turn over or jump off the drive
- Tie band assures high lateral rigidity, guiding the belt in a straight line and preventing it from coming off the drive
- Concave sidewalls provide proper cord support and full contact with the sheave-groove for equal loading and uniform wear
- Flex-bonded cords result in equal load distribution and absorption of bending stress without cord deterioration
- Oil-resistant with RMA standards compliance and cogged construction for improved flexibility
Technical Specifications
Section Size: 5VX | Top Width: 1.25 in | Outside Length: 85 in | Height: 0.5469 in | Strands: 2 | Rib Width: 5/8 in | Reinforcing Cord: Polyester | Material: Ethylene | Operating Temperature: -60°F to +250°F | Oil Resistance: Yes | Construction: Molded Notch Cogged, Banded | Standards: RMA Compliant | Manufacturer: Gates Corporation | Part Number: 9389-2085
Typical Applications
The Gates 2/5VX850 is used in industrial power transmission drives where space constraints and high horsepower demands require efficient multi-belt solutions. Typical installations include compressors, fans, conveyor systems, and machinery where pulsating or shock loads are present.
Compatibility & Replacements
Compatible With
- Standard 5VX sheave grooves
- Multi-belt drive systems (PowerBand configuration)
- Industrial power transmission equipment rated for 5VX section belts
Replaces / Drop-In Replacement For
This Gates part number 9389-2085 is the specific designation for the 2/5VX850 configuration. Verify with original equipment documentation for exact compatibility with your drive system.
Works With
- Gates-compatible 5VX section sheaves
- Standard V-belt drive assemblies
- PowerBand belt tension and alignment systems
