Overview
The Gates 28008MGT20 PowerGrip GT2 timing belt is a high-performance synchronous belt engineered for applications requiring precise timing and reliable power transmission. With dual-sided teeth configuration, this belt delivers 100% load capacity from either side, enabling contra-rotating drives and flexible system configurations. The modified curvilinear tooth profile—Gates’ proprietary GT tooth design—ensures superior engagement with matching pulleys and reduced backlash compared to trapezoidal belt systems.
Key Features
- Dual-sided tooth design — equal load capacity on both belt surfaces for bidirectional drive applications
- Non-slip positive drive — fiberglass tensile cords and nylon tooth facing eliminate slip in timing-critical systems
- Neoprene body — resists moisture and contaminants, extending service life in harsh environments
- Low-noise operation — running at low noise due to nylon-faced teeth and modified tooth profile
- Extended temperature range — rated -30°C to +100°C (-22°F to +212°F) for industrial environments
- Higher torque capacity — double loading capacity over equivalent Twin Power PowerGrip HTD
Technical Specifications
- Pitch: 8mm GT2
- Width: 20mm
- Profile: PowerGrip GT2 (modified curvilinear tooth)
- Material: Neoprene body with fiberglass tensile cord and nylon tooth facing
- Operating Temperature: -30°C to +100°C (-22°F to +212°F)
- Tooth Configuration: Dual-sided (Twin Power)
- Load Capacity: 100% rated load from either belt surface
- Pulley Compatibility: perfect fit on HTD profile pulleys
Typical Applications
The Gates 28008MGT20 PowerGrip GT2 suits precision motion control systems across industrial automation, manufacturing equipment, and power transmission drives. Ideal for applications such as 3D printers where precise synchronization is critical. Eliminates lubrication and re-tensioning reduce maintenance and labor as compared to roller chain drives. Commonly used in:
- Industrial automation and robotics
- Packaging and labeling machinery
- Textile and printing equipment
- Precision positioning systems
- Contra-rotating drive systems
- Low-speed, high-torque applications
Compatibility & Replacements
Compatible With
- Gates PowerGrip GT2 pulleys and sprockets
- Gates PowerGrip GT2 idler sprockets and tensioners
- Compatible with Genuine Gates 2GT, GT2, and GT3 components in 2mm tooth pitch
- 8mm pitch pulley systems in industrial motion control
- Twin Power contra-rotating drive configurations
Replaces / Drop-In Replacement For
The Gates 28008MGT20 is a standard part number in the PowerGrip GT2 8mm pitch, 20mm width category. PowerGrip GT2 – 8 & 14mm Belts can be used to replace other non-Gates curvilinear belts in the next smallest width. For specific replacement compatibility, verify original belt specifications with your system integrator.
Works With
- Gates PowerGrip GT2 drive systems
- Precision synchronous timing applications
- HTD profile pulley systems
- Industrial automation control systems requiring backlash minimization
