The Gates 12505M15 PowerGrip HTD timing belt is a high-performance synchronous belt engineered for precision industrial applications. Gates PowerGrip HTD Timing Belts are high-performance power transmission belts designed for precision industrial applications. This timing belt combines proven tooth geometry with durable construction to provide reliable, maintenance-free operation in equipment requiring exact timing and positive drive engagement.
Key Features
- Unique curvilinear tooth geometry that optimises load distribution and eliminates stress concentration at tooth roots, enabling higher power capacity and extended service life.
- No slippage, high mechanical efficiency, and constant driven speeds.
- Fiberglass tensile cord provides high strength, excellent flex life and high resistance to elongation.
- Nylon tooth facing provides a durable wear surface for long service life.
- Maintenance-free, clean solution with no lubrication or retensioning required.
- Conforms to ISO 13050 standards.
Technical Specifications
The Gates 12505M15 features HTD tooth profile geometry with the following characteristics:
- Tooth Pitch: HTD profile with 5mm pitch (standard PowerGrip HTD specification)
- Belt Width: 15mm
- Pitch Length: 1250mm (approximately 125 teeth)
- Tensile Cord: Fiberglass reinforced
- Tooth Facing: Nylon compound
- Body Material: Neoprene (polychloroprene) elastomer
- Maximum Load Capacity: Up to 1,000 kW (per series specifications)
- Operating Temperature Range: -30°C to +100°C
- Standards Compliance: ISO 13050:2014
