Overview
The FYH FCX07E is a FYH flange mount bearing unit featuring a compact round flange design with 4-bolt mounting. This medium duty four-bolt flanged unit has a 35mm shaft diameter and is constructed of cast iron for strength and durability. The FCX07E housing accommodates a UCX07 sealed ball bearing insert, making it suitable for a wide range of industrial power transmission and motion control applications including material handling, conveyor systems, and rotating machinery.
Key Features
- 4-bolt flange design with hexagon socket set screws
- Pre-lubricated and fitted with a sealed bearing insert for long-lasting durability
- Self-aligning design that can adjust for shaft deviation and reduce abnormal load
- Grease hole and fitting for effortless re-lubrication and smooth operation
- UCX07 bearing insert can be easily removed and replaced without replacing the housing
Technical Specifications
The FCX07E provides reliable performance in mid-range industrial bearing applications:
- Shaft Bore Diameter: 35mm
- Bearing Insert Type: UCX07 (sealed deep groove ball bearing)
- Mount Type: 4-bolt round flange
- Housing Material: Cast iron
- Duty Rating: Medium duty
- Set Screw Type: Hexagon socket
- Re-lubrication: Grease fitting and grease hole
- Bearing Condition: Pre-lubricated at factory
Typical Applications
The FYH YCX07 UC508 FCX07E is commonly applied in:
- Conveyor and material handling systems
- Rotating machinery and spindles
- Agricultural and textile equipment
- General industrial power transmission
- Food processing and packaging machinery
Compatibility & Replacements
Compatible With
- UCX07 sealed ball bearing inserts (medium duty)
- Other compatible bearing inserts designed for FCX07 round flange housings
- 35mm shaft applications with 4-bolt flange mounting
- Standard grease fittings (1/4-28 UNF for this size class)
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. The FCX07E housing is specific to FYH’s flange-mount series and accepts UCX07-series bearing inserts.
Works With
- FYH bearing insert lineup (UC, UK, UCP, and UKP series inserts where bore matches)
- Standard industrial coupling and drive configurations
- Conventional greases and lubrication systems
- Maintenance-free sealed bearing operation or field re-lubrication as needed
