Overview
The Fuji Electric PHC66002-AA0YV is a microjet chart recorder engineered for industrial process monitoring and data acquisition. This 6-channel recorder uses precision microjet ink printing technology to capture real-time process data on fan-fold chart paper. The PHC66002-AA0YV offers independent channel configuration and support for diverse input signal types, making it suitable for temperature monitoring, pressure recording, and multi-parameter process control in manufacturing, testing, and quality assurance environments.
Key Features
- Six independent recording channels with microjet ink printing for continuous traces without pen offset
- Support for multiple input types: thermocouples (12 kinds), resistance bulbs (Pt100), and DC voltage/current signals
- Six-color channel recording with no apparent phase difference
- Prints symbols, figures, and letters on standard fan-fold chart paper
- Compact panel-mount design suitable for OEM integration and laboratory use
- Reusable ink cartridges for cost-effective operation
Technical Specifications
| Model | PHC66002-AA0YV |
| Recording Channels | 6 channels |
| Recording Method | Microjet ink printing |
| Recording Colors | 6 colors |
| Input Signal Types | Thermocouples (K, R, S, E, J, T, N, U, B, W, L, P), Resistance bulbs (Pt100), 1-5V DC, 4-20mA DC, 10-50mA DC, ±50mV to ±50V DC |
| Chart Paper Width | Fan-fold standard (PEX00BL1-1000B format) |
| Power Supply | 100-240V AC |
| Recording Cycle | 2 seconds minimum |
| Product Type | Chart Recorder / Data Logger |
| Manufacturer | Fuji Electric Co., Ltd. |
Typical Applications
- Temperature monitoring and recording in industrial processes and furnaces
- Multi-parameter pressure and flow data acquisition in manufacturing
- Quality control testing with simultaneous monitoring of multiple sensor inputs
- Laboratory measurement and data logging for research and development
- Process validation and compliance documentation for regulated industries
- Equipment performance trend analysis in facility maintenance programs
Compatibility & Replacements
Compatible With
- Thermocouple sensors (all 12 standard types)
- Pt100 resistance temperature detectors (RTDs)
- DC voltage signal sources (5mV to 50V ranges)
- DC current signal sources (4-20mA, 10-50mA)
- Standard fan-fold chart paper (PEX00BL1-1000B and compatible formats)
- Panel-mount configuration in industrial control cabinets and instrument panels
Replaces / Drop-In Replacement For
For specific replacement information, verify model compatibility with your system integrator or Fuji Electric technical support before ordering. PHC series recorders are designed as direct replacements within the same model generation.
Works With
- Thermocouple transmitters and signal conditioners
- Temperature sensors and process transmitters
- PLC analog input modules and data acquisition systems
- Industrial process control systems requiring chart-based data logging
- Standard instrumentation power distribution (100-240V AC)
