Overview
The Flo-Tork 15000-90-CB-ES-MS13X-SBH-NLX-XP is a professional-grade hydraulic rotary actuator manufactured by Moog, designed for industrial automation and machinery applications requiring precise angular positioning. Operating at a maximum pressure of 3000 PSI, this double-acting unit delivers consistent performance across heavy-duty manufacturing, construction, and material handling environments.
Key Features
- 90-degree rotation range for precise angular control
- Double-acting configuration for bidirectional operation
- 3000 PSI maximum rated pressure
- Compact rotary cylinder design suitable for space-constrained installations
- Industry-standard Moog/Flo-Tork construction and reliability
- Suitable media: hydraulic fluid (ISO VG 46 recommended)
Technical Specifications
- Maximum Pressure: 3000 PSI
- Rotation Angle: 90 degrees
- Actuator Type: Rotary Cylinder
- Configuration: Double-Acting
- Suitable Media: Hydraulic Fluid (ISO VG 46)
- Displacement (90°): Approx. 8.76 in³ (based on 15000 series)
- Port Configuration: SAE/ISO standard flanges
- Mounting: Flange-mount with integral porting
- Manufacturer: Moog Industrial
- Series: Flo-Tork 15000
Typical Applications
- Industrial machinery and automated production lines requiring rotary motion control
- Construction and material handling equipment
- Positioning and clamping systems in manufacturing
- Agricultural and mobile hydraulic systems
- Valve and damper control actuators
- Any application requiring precise 90-degree angular actuation under high pressure
Compatibility & Replacements
Compatible With
- Hydraulic systems operating at or below 3000 PSI
- Mobile and stationary hydraulic equipment
- ISO 4401 (CETOP 05) and SAE NG10 (CETOP 03) manifold systems
- Standard hydraulic pump circuits with proportional or directional spool valves
- Industrial PLC-controlled automation systems with proportional valve integration
Replaces / Drop-In Replacement For
- Other Moog Flo-Tork 15000 series units with matching port configuration and displacement requirements
- Vickers, Bosch Rexroth, Eaton, and Parker equivalent 90-degree rotary actuators rated for 3000 PSI (verify pin configuration and porting before installation)
- Legacy industrial rotary actuators of similar displacement and pressure rating
Works With
- Proportional directional control valves (4/3 and 4/2 spool types)
- Pressure relief valves and system protection devices
- Pilot-operated check valves for load holding
- Flow control needles and meter-out circuits for speed adjustment
- Industrial SCADA systems and PLC platforms via proportional valve command interface
- Standard hydraulic hoses and SAE/ISO flange adapters
