Overview
The EPIC 10196000 connector insert is a male contact module designed for industrial power distribution and signal systems. This 24-pin H-BE series insert delivers 16A rated current at 500V (IEC standard), making it suitable for machinery control, power supplies, and automated manufacturing environments. Manufactured by LAPP under the EPIC brand, the 10196000 combines durability with straightforward screw-terminal installation.
Key Features
- 24-pin male contact insert for H-B 24, Ultra H-B 24, and QUICK & EASY housings
- 16A current rating (IEC) at 500V voltage rating (IEC)
- Screw termination with integrated wire protection leaves
- Hard silver-plated copper alloy contacts for corrosion resistance
- Wire acceptance: 0.5–2.5mm² cross-section (Group C rated)
- Temperature range: –40°C to +100°C for stable operation in varied environments
Technical Specifications
- Rated Current: 16A (IEC)
- Rated Voltage: 500V (IEC)
- Contact Type: Male
- Number of Pins: 24
- Termination Method: Screw with wire protection
- Wire Cross-Section: 0.5–2.5mm²
- Contact Material: Copper alloy with hard silver plating
- Operating Temperature: –40°C to +100°C
- Series: H-BE
- Part Number: 10196000
Typical Applications
- Industrial machinery and production line control systems
- Electrical power distribution panels and switchgear
- Motor drive and servo control circuits
- Automated test and measurement equipment
- Energy-efficient factory automation hubs
Compatibility & Replacements
Compatible With
- LAPP EPIC H-B 24 connector housings
- LAPP Ultra H-B 24 integrated housings
- LAPP QUICK & EASY mount systems
- Standard IEC 500V / 16A power distribution networks
- Industrial control cabinets and DIN-rail mounted equipment
Replaces / Drop-In Replacement For
The EPIC 10196000 is a direct insert replacement within the EPIC H-BE family for 24-pin male connector applications. Verify compatibility with your specific housing assembly before installation to ensure proper mechanical and electrical alignment.
Works With
- LAPP EPIC connector hoods and shields
- Standard M20 and PG21 cable glands
- Industry-standard crimp and screw-terminated wire terminals
- ISO 16 and ISO 20 conductor gauge specifications
