Overview
Dodge 113694 is a precision-engineered Dyna-Sync timing belt pulley designed for demanding mechanical power transmission and industrial automation applications. The TL20H150-1210 configuration delivers synchronized belt engagement with minimal backlash and exceptional durability, making it ideal for conveyor systems, material handling equipment, and industrial machinery.
Key Features
- Synchronized, no-slip transmission for accurate power delivery
- Taper-Lock bore design with 1/2″ to 1-1/4″ bore diameter range for flexible shaft coupling
- Requires 1210 bushing series for secure, easy on/off installation
- Flanged design standard to prevent belt drift on horizontal and angled shafts
- Virtually backlash-free operation with constant linear velocity
- No lubrication required, reducing maintenance downtime
- ISO 9000 precision-manufactured construction
Technical Specifications
This H-series pulley operates at 1/2″ pitch with robust tooth geometry and proven reliability across industrial sectors:
- Belt type: H series (1/2″ pitch)
- Tooth count: 20 grooves
- Pitch diameter: 3.183″
- Outside diameter: 3.44″
- Belt width: 1.5″ (requires 1/2″ pitch belt)
- Face width: 1.86″
- Flange diameter: 3.44″
- Hub projection: 0.11″
- Weight: 2.2 lbs
Typical Applications
The Dodge 113694 Dyna-Sync pulley is widely deployed in:
- Conveyor and material handling systems requiring synchronized drive ratios
- Industrial automation equipment with precision speed control
- Printing and textile machinery with exacting synchronization requirements
- Drive systems requiring low-backlash, constant-velocity transmission
- Food processing and packaging machinery
- OEM equipment where reliability and minimal maintenance are critical
Compatibility & Replacements
Compatible With
- H-series timing belts with 1/2″ pitch spacing
- Taper-Lock bushings (1210 series required)
- Shafts with 1/2″ to 1-1/4″ bore diameter
- Mechanical power transmission systems using synchronous drive technology
- Industrial equipment requiring Dyna-Sync pulley configuration
Replaces / Drop-In Replacement For
- Direct replacement for Dodge model 113694 applications
- Interchangeable with equivalent TL20H150-1210 specifications from original equipment OEM documentation
- Verify compatibility with your system integrator before ordering
Works With
- H-series timing belts (HTD, XL profiles compatible with 1/2″ pitch)
- Standard Taper-Lock QD bushing mounting systems
- Both horizontal and vertical shaft installations with proper flanged pulley configuration
- Industrial synchronous drive assemblies and multi-pulley transmission systems
