Overview
The Dodge F2B-SCEZ-012-PCR is a 204 Series setscrew ball bearing engineered for reliable performance in industrial machinery, HVAC systems, and washdown environments. This two-bolt flange-mount unit features a 3/4-inch bore diameter with a corrosion-resistant polymer housing and integrated E-Z-Kleen protection system. Manufactured in the USA, the Dodge F2B-SCEZ-012-PCR delivers long-lasting durability and straightforward installation for maintenance and replacement applications.
Key Features
- 3/4-inch bore diameter — fits standard shaft sizes for seamless power transmission
- Two-bolt flange mount design — simplifies alignment and installation in tight mounting spaces
- Polymer E-Z-Kleen housing — provides superior corrosion resistance and is ideal for wet, washdown applications
- Setscrew locking device — 65-degree setscrew secures the bearing firmly to the shaft
- Triple-lip QuadGuard seal with flingers — protects against water, dust, and contaminants while retaining MobilGrease FM222 lubricant
- Relubricatable design — supports extended maintenance intervals and operational life
- Non-expansion (fixed) bearing — provides stable, consistent performance under load
Technical Specifications
- Series: 204 (Normal Duty)
- Bearing Type: Setscrew Ball Bearing
- Bore Diameter: 3/4 inch
- Bore Length: 1.48 inches
- Bolt Center-to-Center: 3.54 inches
- Overall Length/Diameter: 4.45 inches
- Overall Depth: 1.43 inches
- Overall Height: 2.35 inches
- Housing Material: Polymer (corrosion-resistant)
- Insert Material: Plated steel (nickel-composite)
- Seal Type: Triple-Lip Contact Seal (QuadGuard)
- Locking Device: 65-degree setscrew
- Expansion Type: Non-Expansion (Fixed)
- Lubrication: Grease (MobilGrease FM222)
- Dynamic Load Rating: 2899 lb
- Static Load Rating: 1482 lb
- Maximum Speed: 6000 rpm
- Operating Temperature: -20°F to 225°F
- Country of Origin: USA
- Mounting Type: 2-Bolt Base Flange
- UPC: 782475985999
- Manufacturer Part Number: 127524
Typical Applications
- Conveyor systems — belt and roller conveyors requiring reliable, low-maintenance bearings
- Washdown environments — food processing, beverage production, and dairy equipment where moisture resistance is critical
- HVAC systems — heating, ventilation, and air conditioning units demanding smooth, quiet operation
- Agricultural equipment — combines durability with protection against dust and environmental stress
- Industrial machinery — assembly lines, pumps, and general industrial power transmission
- Manufacturing equipment — reliable support for machinery spindles and drive shafts
Compatibility & Replacements
Compatible With
- Standard industrial motors and gearmotors with 3/4-inch shafts
- Mechanical power transmission systems (conveyors, pumps, fans)
- HVAC equipment and components
- Agricultural machinery requiring 2-bolt flange mounts
- Industrial assemblies and custom machinery
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. The Dodge F2B-SCEZ-012-PCR has a matching equivalent in stainless steel housing (F2B-SCEZ-012-SHCR, catalog number 127681) for corrosive environments. Similar bore-size models in the Dodge E-Z-Kleen 204 Series include the F2B-SCEZ-010L-PCR (5/8-inch bore), though these are not direct substitutes.
Works With
- Dodge 204 Series bearing systems and accessories
- Standard flange-mount shaft coupling and adapter kits
- Industrial-grade grease and lubricant systems compatible with MobilGrease FM222
- Standard fastening hardware for 2-bolt flange installations
- Maintenance tools and re-lubrication systems for relubricatable bearing designs
