Overview
The DM9601-7S connector is a 7-position circular receptacle manufactured by TE Connectivity Deutsch. This rugged connector is part of the Deutsch Engineered Connector Series, a proven family of circular connectors designed to deliver reliable electrical connections across demanding industrial, military, aerospace, and commercial aircraft applications. The socket contact configuration (-S designation) ensures secure mating with pin-configured counterparts in high-vibration and harsh-environment installations.
Key Features
- 7-position insert arrangement for multi-conductor applications
- Socket contacts (-S) for secure mating with standard pin connectors
- Automotive-standard coaxial cable design with flexible routing
- Jam nut receptacle style for robust panel mounting
- Proven reliability in aerospace, military, and industrial equipment
- Protective cap compatibility with existing CPC housings
Technical Specifications
- Part Number: DM9601-7S
- Manufacturer: TE Connectivity / Deutsch
- Insert Arrangement: 7-position
- Contact Style: Socket (S)
- Connector Type: Circular Receptacle (Jam Nut)
- Shell Size: Deutsch standard (refer to detailed drawings)
- Cable Compatibility: Automotive-standard coaxial cable
- Environmental Rating: Industrial, aerospace, military grade
Typical Applications
- Aerospace and commercial aircraft electrical systems
- Military vehicle and equipment interconnections
- Industrial machinery and control systems
- Ruggedized test and measurement equipment
- Harsh-environment panel-mount installations requiring vibration resistance
Compatibility & Replacements
Compatible With
- Deutsch DM9700 series straight plugs
- Deutsch DM9702 series plugs with clamp
- Standard CPC (Circular Plastic Connector) plug and receptacle systems
- Existing MATE-N-LOK universal cap housings
- Automotive-standard coaxial cable terminations
Replaces / Drop-In Replacement For
- DM9601-7S-044 (alternate part variant)
- DM96017S044 (alternate format designation)
- NSN 5935-00-816-7558 (military specification equivalent)
Works With
- Deutsch circular connector strain relief systems (crimp and screw options)
- Standard 20GA, 16GA, and 12GA wire gauges per insert arrangement chart
- Ruggedized and Quick Lock strain relief variants
- Military and aerospace connector ecosystem (MIL-DTL specifications)
