Overview
The Dayton 6X154G is an industrial-grade time delay relay designed for off-delay timing applications requiring precision and reliability. With its adjustable 1.8–180 second delay range and 10A DPDT output contacts, this relay provides flexible timing control for industrial machinery, HVAC systems, and circuit protection applications. The 120VAC input voltage and octal socket base make this unit a drop-in replacement for standard timing circuits.
Key Features
- Off-delay timing function with 1.8–180 second adjustable range
- 10A DPDT (double-pole, double-throw) contacts rated for 120VAC and 240VAC
- 120VAC/DC coil voltage with low power consumption (2.5VA, 2.0W)
- 11-pin octal socket base for standard relay mounts
- Potentiometer adjustment for precise timing calibration
- Solid-state construction for reliable, repeatable performance
Technical Specifications
- Input Voltage: 120VAC/DC
- Contact Configuration: DPDT (Double-Pole, Double-Throw)
- Contact Rating: 10A @ 240VAC; 10A @ 30VDC
- Time Range: 1.8–180 seconds (adjustable)
- Base Type: Octal plug-in socket
- Number of Pins: 11
- Power Consumption: 2.5VA, 2.0W
- Body Dimensions: 2.40″ W × 1.70″ D × 2.90″ H
- Overall Height: 3.10″
- Adjustment Method: Potentiometer
- Contact Material: Silver Nickel
Typical Applications
- HVAC systems requiring compressor soft-start or pump motor shutdown delay
- Industrial control circuits needing off-delay timing protection
- Water pump and circulation system startup sequencing
- Motor protection circuits with delayed de-energization
- Fan motor and equipment cooling-down cycles
- General-purpose timing and sequencing in panel-mounted controls
Compatibility & Replacements
Compatible With
- Standard 11-pin octal relay sockets (6X156, 1EGP2, 1EGP4)
- 120VAC control circuits and industrial automation panels
- HVAC control systems and mechanical time-delay applications
Replaces / Drop-In Replacement For
- Dayton model variants: 6X154N, 6X154M, 6X154B, 6X154E, 6X154C, 6X154F
- Potential equivalent: 1EGC5 (verify compatibility with your system integrator)
Works With
- Standard octal relay sockets and mounting blocks
- 120VAC industrial control wiring and panel circuits
- Electromechanical and solid-state relay base systems
