Overview
The Eaton Cutler-Hammer D23MR802 is a Type M latched relay engineered for demanding industrial control and automation applications. This NEMA-rated relay delivers dependable switching performance in machine tool, process control, and conveyor systems. The latched mechanism allows the relay to hold its state without continuous coil power, reducing energy consumption while maintaining reliable circuit control.
Key Features
- Latched Operation: Maintains state without continuous power supply, reducing power consumption and increasing efficiency
- Type M Reversible Contacts: Convertible contact configuration for flexible control circuit design
- 10 Ampere Contact Rating: Handles standard industrial load requirements at 300V AC
- NEMA Rated: Built to recognized industrial standards for machine tool and process control use
- Compact Industrial Design: Drops into existing control panels and retrofit applications
Technical Specifications
- Relay Type: Type M Latched Relay
- Manufacturer: Eaton Cutler-Hammer
- Part Number: D23MR802
- Contact Rating: 10 Amperes
- Voltage Rating: 300V AC Maximum
- Mechanism: Latched (Maintains state without continuous power)
- Contact Type: Reversible/Convertible
- Standard: NEMA Machine Tool Relay
- Application Class: Industrial Control & Automation
Typical Applications
- Motor control circuits and relay-based motor start/stop systems
- Machine tool automation and sequencing logic
- HVAC and process control systems
- Conveyor and material handling equipment
- Industrial automation control panels
- PLC-driven automation systems requiring latched switching
- OEM equipment builds and system retrofits
Compatibility & Replacements
Compatible With
- Eaton Cutler-Hammer control panel systems
- NEMA machine tool relay applications
- Standard industrial 120V control circuits
- Motor control and PLC-based automation platforms
- Process control and conveyor systems
Replaces / Drop-In Replacement For
The D23MR802 is part of the Eaton Type M relay family. Verify compatibility with your system integrator before ordering replacement or interchange applications.
Works With
- Eaton Cutler-Hammer control relay accessories
- Standard industrial 60 Hz control circuits
- NEMA-rated motor control systems
- Automation control logic and sequencing platforms
