Overview
The PG-35-102R-PR2 pressure gauge from Nidec Copal (formerly Copal Electronics) is a reliable digital manometer designed for measuring pressure in both air and liquid applications. This sensor-based gauge delivers precision measurement and includes an integrated cable for simplified installation in industrial automation systems, control panels, and test equipment. The unit ships factory-configured and is suitable for OEM integration and retrofit applications.
Key Features
- Dual-medium operation: Measures air and liquid pressure in the same device
- Integrated cable included for quick connection to monitoring systems
- Configurable operating modes (R/G/V settings) for application flexibility
- Factory pre-set configuration (102R model ships in V-3 mode)
- Compact digital display interface for clear pressure readout
- Suitable for laboratory and manufacturing measurement tasks
Technical Specifications
- Model: PG-35-102R-PR2
- Product Type: Manometer (Pressure Gauge)
- Media Compatibility: Air and Liquid pressure measurement
- Cable: Integrated (included)
- Operating Modes: R, G, V (switchable; 102R supports modes 1, 2, or 3)
- Factory Default Setting: V-mode set to “3” for 102R variant
- Tolerance: ±0.5 mm (unless otherwise specified)
- Series: PG-35 (Nidec Copal Electronics)
- Condition: New in Box
Typical Applications
- Pneumatic and hydraulic circuit monitoring in manufacturing equipment
- Laboratory pressure measurement and calibration
- Industrial automation system diagnostics and troubleshooting
- Vacuum and positive pressure testing
- OEM control panel integration and embedded sensor applications
Compatibility & Replacements
Compatible With
- Nidec Copal PG-35 series pressure monitoring systems
- Industrial automation control panels requiring air/liquid pressure feedback
- Pneumatic and hydraulic test and measurement equipment
- Laboratory scientific instruments and environmental testers
Replaces / Drop-In Replacement For
- Other PG-35 series variants with identical mounting and cable interface (verify connector type before ordering)
- Consult Nidec Copal documentation or a system integrator to confirm interchangeability with predecessor models
Works With
- Standard industrial pressure transducer interfaces and monitoring systems
- Laboratory data acquisition equipment compatible with sensor-based manometer output
- Nidec Copal pressure gauge accessory packages and calibration equipment
