Overview
The CKD NVP11-10A-12HS-3 is a universal air operated 3-port solenoid valve featuring a solenoid-mounted design. As part of the NVP11 series, this valve combines compact construction with proven reliability for pneumatic control applications. The 10A body size provides an Rc 3/8 connection port, making it suitable for systems requiring controlled air flow distribution in automation, manufacturing, and general industrial equipment.
Key Features
- Universal type actuation for flexible system integration
- Solenoid valve mounted design with grommet coil housing
- Rc 3/8 connection port size (10A body)
- Aluminum body with nitrile rubber seals for durability
- Manual override operation included as standard
- Compact form factor ideal for space-constrained installations
Technical Specifications
- Manufacturer: CKD Corporation, Japan
- Series: NVP11 (Air Operated 3-Port Valve)
- Port Size: Rc 3/8 (10A)
- Body Material: Aluminum
- Seal Material: Nitrile Rubber
- Coil Housing: Standard Grommet Coil (12HS designation)
- Valve Type: 3-Port, Solenoid Valve Mounted
- Operating Condition: Lubrication-free compatible
- Manual Override: Yes (non-locking standard)
Typical Applications
The NVP11-10A-12HS-3 is widely used in:
- Pneumatic automation systems and production lines
- Machine tool air distribution and control
- Factory automation valve manifolds
- Industrial equipment air flow switching
- General purpose pneumatic circuit control
Compatibility & Replacements
Compatible With
- Standard pneumatic systems operating at 0.5 MPa supply pressure
- Industrial automation platforms using solenoid-controlled air distribution
- Manifold-integrated pneumatic circuits
- Lubrication-free and pre-lubricated air supplies
Replaces / Drop-In Replacement For
The CKD NVP11-10A-12HS-3 is a direct replacement for other 10A body variants within the NVP11 series with matching coil specifications. Verify valve cavity alignment and solenoid pinout compatibility with your system integrator before ordering to ensure drop-in compatibility.
Works With
- CKD solenoid coils matching 12HS grommet coil specification
- Standard pneumatic terminal lubrication systems
- Industrial pneumatic schematic design (ISO 1219 compliant)
- Pilot-operated and direct-acting pneumatic control systems
