Overview
The Chyuan I CI-670N panel meter is a Class 2.5 analog instrument engineered for accurate electrical parameter measurement in industrial and business environments. With its proven accuracy classification and durable construction, this panel meter provides reliable readings for voltage, current, and other electrical quantities in control systems and measurement applications.
Key Features
- Class 2.5 accuracy rating for precise measurements
- Compact panel-mount design for easy integration into control enclosures
- Analog moving-coil mechanism for straightforward operation
- Robust construction for industrial durability
- Direct panel mounting without additional hardware
Technical Specifications
The CI-670N is manufactured to international standards for electrical panel meters. Class 2.5 accuracy ensures measurements within ±2.5% of full scale, making this meter suitable for general industrial applications, process monitoring, and equipment diagnostics. The meter features standard panel cutout dimensions for 70×60 mm applications and operates across typical industrial temperature and humidity ranges.
Typical Applications
- Industrial process monitoring and control panels
- Electrical system measurement and diagnostics
- Equipment performance verification
- HVAC and machinery monitoring systems
- General-purpose electrical measurement in commercial and industrial facilities
Compatibility & Replacements
Compatible With
- Standard 70×60 mm panel cutout openings
- Analog meter circuits and shunt configurations
- Industrial control enclosures and switchboards
- DC and AC measurement applications (configuration-dependent)
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. The CI-670N is a Class 2.5 meter and may directly replace other analog panel meters in the same accuracy class with matching dimensions and measurement ranges.
Works With
- External current transformers (CT) or shunt resistors as required by application
- Standard industrial wiring practices and terminal block connections
- Conventional analog meter measurement circuits
