Overview
The Burkle Schock ER2234 control transformer is a compact, industrial-grade power transformer designed to step down multi-tap primary voltages (220, 400, 440, or 575 VAC) to a stable 24 VDC secondary supply. Rated at 43 VA with single-phase construction, this unit provides regulated control power for pilot lights, solenoids, relays, and low-voltage circuits in machine tool, manufacturing, and OEM panel applications. Screw terminal connections ensure secure, vibration-resistant installations in demanding industrial environments.
Key Features
- Multi-tap primary accepts 220, 400, 440, or 575 VAC inputs
- 24 VDC secondary output rated at 0.60–1.8 amp
- 43 VA transformer capacity (0.043 KVA)
- Single-phase, 50 Hz operation
- Screw terminal blocks for reliability and serviceability
- Compact, durable construction suitable for control panels and DIN rail mounting
Technical Specifications
- Manufacturer: Burkle Schock
- Model Number: ER2234
- Primary Voltage (Multi-Tap): 220, 400, 440, 575 VAC
- Secondary Voltage: 24 VDC
- Secondary Current Rating: 0.60–1.8 amp
- Frequency: 50 Hz
- Power Rating: 0.043 KVA (43 VA)
- Connection Type: Screw terminal
- Weight: 5.50 lbs
- Enclosure: Industrial duty case
Typical Applications
The ER2234 is widely deployed in:
- Industrial control panels and cabinets
- Machine tool control circuits
- OEM equipment and automation systems
- Solenoid and relay supply circuits
- Pilot light and indicator lamp power
- Low-voltage logic and PLC input card supplies
- Manufacturing process automation equipment
Compatibility & Replacements
Compatible With
- Industrial control cabinet installations with multi-voltage primary feeds
- 24 VDC control supply systems in factory automation
- Standard DIN rail and panel-mount enclosure systems
- Screw terminal wiring practices in industrial controls
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator or panel builder before ordering. The ER2234 may replace equivalent single-phase, 24 VDC output transformers with comparable VA ratings and multi-tap primary options. Cross-reference the original equipment part number with Burkle Schock documentation to confirm mechanical and electrical fit.
Works With
- Low-voltage DC logic and PLC control circuits
- Solenoid and relay coil supplies (24 VDC)
- Industrial operator panels and push-button stations
- Standard industrial power distribution and control systems
- DIN-mounted panel-build applications
