Overview
The Brooks Sho-Rate 1350EFC8BGC1A is a precision low-flow glass tube variable area flow meter designed for accurate, reliable measurement in industrial fluid systems. This rotameter delivers consistent performance across hydraulic, pneumatic, and plumbing applications where repeatability and durability matter.
Key Features
- 10% accuracy with 10:1 flow rangeability for flexible measurement ranges
- Glass tube construction with integrated magnifier for easy readout
- Direct-reading scales customizable for common units and fluids
- Optional integral needle control valves and flow controllers
- Borosilicate glass resistant to thermal shock and corrosive gases/fluids
- Integral float stops prevent float loss during maintenance
- Easy-change tube assembly design for quick interchangeability
Technical Specifications
| Manufacturer | Brooks Instrument |
| Model | Sho-Rate 1350EFC8BGC1A |
| Type | Low-Flow Glass Tube Variable Area Flow Meter (Rotameter) |
| Accuracy | 10% of full scale |
| Rangeability | 10:1 flow range |
| Tube Material | Borosilicate glass |
| Scale Type | Direct-read with built-in magnifier |
| Valve Options | Standard multi-purpose valve, optional needle control or flow controllers |
| End Fittings | 5/16-24 integral threads (configurable material options) |
| Applications | Hydraulics, pneumatics, pumps, plumbing, industrial process measurement |
| Service & Calibration | Worldwide repair facilities with ISO 9001 certified recalibration |
Typical Applications
The Brooks Sho-Rate 1350EFC8BGC1A is well-suited for:
- Hydraulic and pneumatic system monitoring and control
- Low-flow process measurement in chemical and industrial plants
- OEM integration for machinery and analyzer systems
- Laboratory and analytical flow measurement
- HVAC and plumbing system commissioning and diagnostics
- Cost-effective flow verification where 10% accuracy is acceptable
Compatibility & Replacements
Compatible With
- Industrial fluid handling systems requiring low-flow measurement
- Pneumatic and hydraulic supply networks
- Direct-read instrumentation panels and flow control stations
- Systems requiring no electrical power (passive rotameter operation)
- Customizable scale ranges for various fluid types and units of measure
Replaces / Drop-In Replacement For
The Sho-Rate 1350 series is a low-flow alternative to standard high-flow meters. For specific model interchangeability, consult your system integrator or Brooks Instrument applications engineering.
Works With
- Inlet and outlet needle control valves (optional)
- Integral cartridge and precision control valves
- Flow controllers for advanced regulation
- ISO 9001 certified recalibration and repair services worldwide
- Passive reading (no external electronics or communication protocols required)
