Overview
The Automation Direct ABP1H41Z11 is a double-insulated IEC limit switch designed for industrial position sensing and machine guarding. This limit switch delivers reliable snap action switching with a compact 41mm wide body and adjustable head for flexible mounting in diverse applications including conveyors, machine beds, guard doors, and automated production lines.
Key Features
- Side rotary lever with polyamide roller actuator for smooth operation and wear resistance
- 90-degree adjustable head allows fine-tuning of switch position to match application geometry
- Snap action contacts (1 N.O. / 1 N.C.) ensure fast, positive switching transitions
- Double-insulated construction for enhanced safety in harsh industrial environments
- PG13.5 cable entry for standard conduit connections
- Compact 41mm body footprint simplifies integration into space-constrained assemblies
Technical Specifications
- Contact Configuration: 1 N.O. (normally open) / 1 N.C. (normally closed)
- Action Type: Snap action
- Actuator: Side rotary lever with polyamide roller
- Body Width: 41mm
- Head Style: 90-degree adjustable
- Insulation Class: Double-insulated
- Cable Entry: PG13.5
- Standard Compliance: IEC rated
- Operating Temperature: -10 to +70°C (standard); -40 to +70°C (extended range available)
- Condition: New in Box
Typical Applications
- Conveyor belt position sensing and emergency stops
- Guard door and safety interlock switches
- Machine bed and table position detection
- Elevator and lift systems
- Automated production equipment and assembly lines
- End-of-travel and overtravel protection
- Process control position verification
Compatibility & Replacements
Compatible With
- IEC 60947-4-5 rated control systems and safety circuits
- AC and DC power supplies (as per terminal specifications)
- Snap action contact block systems in ABP series assemblies
- Standard industrial PLC and relay control modules
- Machine safety controllers and motor starters
Replaces / Drop-In Replacement For
- Verify compatibility with your system integrator before ordering. ABP series switches use standard IEC mounting and terminal patterns; similar rotary lever models in the ABP product family may share footprints, but always confirm part specifications before substitution.
Works With
- IEC-compliant control circuits and automation systems
- Industrial relay logic and hardwired control panels
- PLC input modules with digital (discrete) sensing capability
- Motor control centers and machine control relays
- Safety-rated control systems (AC-15, DC-13 utilization categories)
