<h2>Overview</h2>
<p>The <strong>Athena 2000-T analog temperature controller</strong> is a 1/4 DIN panel-mounted control device designed for proportional temperature regulation in HVAC, refrigeration, and process heating applications. With a 0–800°F sensing range and 120/240VAC dual voltage input, this unit provides stable, continuous output control suitable for energizing relays, solenoids, and other load devices. The 2000-T model features a metal-case enclosed design with compact form factor ideal for retrofit and replacement installations.</p>
<h2>Key Features</h2>
<ul>
<li>1/4 DIN panel-mount form factor for standard control enclosures</li>
<li>Proportional output control for smooth, continuous regulation</li>
<li>Dual 120/240VAC input voltage compatibility</li>
<li>2A rated output current for relay and solenoid actuation</li>
<li>0–800°F temperature sensing range</li>
<li>Thermocouple or RTD sensor input acceptance</li>
<li>Adjustable set point and proportional band controls</li>
<li>Metal enclosure with dual meter dial display for monitoring</li>
</ul>
<h2>Technical Specifications</h2>
<p>Core operating parameters and physical dimensions:</p>
<ul>
<li><strong>Temperature Range:</strong> 0–800°F</li>
<li><strong>Input Voltage:</strong> 120/240VAC (selectable)</li>
<li><strong>Output Rating:</strong> 2A</li>
<li><strong>Control Type:</strong> Proportional (analog)</li>
<li><strong>Sensor Input:</strong> Thermocouple or RTD</li>
<li><strong>Panel Mount:</strong> 1/4 DIN</li>
<li><strong>Enclosure:</li> Metal case with dial display</li>
<li><strong>Series:</strong> Athena 2000 Series</li>
</ul>
<h2>Typical Applications</h2>
<p>The 2000-T controller is commonly deployed in:</p>
<ul>
<li>HVAC heating and cooling system regulation</li>
<li>Commercial and industrial refrigeration control</li>
<li>Process heating and oven temperature maintenance</li>
<li>Incubator and environmental chamber control</li>
<li>Hot water and steam system modulation</li>
</ul>
<h2>Compatibility & Replacements</h2>
<h3>Compatible With</h3>
<ul>
<li>Standard thermocouple sensors (K, J, T, E types)</li>
<li>RTD sensors (Pt100, Pt1000)</li>
<li>Standard single-pole relay loads and solenoid valves</li>
<li>Modulating heating and cooling equipment</li>
</ul>
<h3>Replaces / Drop-In Replacement For</h3>
<p>Verify compatibility with your system integrator before ordering for exact model interchangeability.</p>
<h3>Works With</h3>
<ul>
<li>Analog proportional control systems</li>
<li>Manual thermostat setpoint adjustment and tuning</li>
<li>Standard HVAC control wiring and enclosures</li>
</ul>
