Overview
The Red Lion OEMJD002 is an electronic temperature controller designed for heating, ventilation, air conditioning, and refrigeration applications. Red Lion Controls manufactures a comprehensive line of industrial temperature control and indication equipment, and the OEMJD002 represents a reliable, ready-to-deploy solution for process and environmental control requirements.
Key Features
- Electronic thermostat design for precise temperature monitoring
- Compact form factor suitable for panel and wall mounting
- Dual display capability for temperature and setpoint visibility
- Sensor diagnostic capabilities including open and short detection
- Industrial-grade construction for harsh HVAC and refrigeration environments
- Alarm output functions for temperature limit detection
Technical Specifications
- Product Type: Electronic Temperature Controller
- Display Type: Dual 4-digit LED (temperature and auxiliary display)
- Upper Display: 0.4″ (10.2 mm) red LED digits
- Lower Display: 0.3″ (7.6 mm) green LED digits
- Input Sensor Types: Thermocouple compatible
- Output Type: Relay and alarm contacts
- Sensor Diagnostics: Open sensor, shorted sensor detection
- Certifications: UL Listed (File #E137808, UL508); CSA C22.2 No. 14-M95
- Communication: RS-485 compatible (up to 32 units per line)
- Response Time: 100 milliseconds maximum
- Manufacturer: Red Lion Controls
Typical Applications
The Red Lion OEMJD002 temperature controller is well-suited for:
- HVAC system thermostat and temperature monitoring
- Refrigeration and cold storage temperature control
- Industrial process heating and cooling applications
- Environmental chamber and test equipment control
- Building automation and climate management
- Ovens, furnaces, and thermal processing equipment
Compatibility & Replacements
Compatible With
- Thermocouple sensors (types T, E, J, K, R, S, B, N, C)
- Standard industrial relay panels and control cabinets
- RS-485 industrial networks (daisy-chain up to 32 units)
- 24 VAC / 18-36 VDC power supplies
- Standard DIN rail mounting configurations
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. The OEMJD002 is a specific OEM part number; consult Red Lion Controls or your controls vendor for confirmed replacement specifications.
Works With
- Red Lion Controls temperature sensing and display equipment
- Standard thermocouple wiring and connectors
- Industrial relay and contactor outputs
- RS-485 communication networks
- Standard industrial control software and HMI platforms
