Overview
The Allen-Bradley 800P-1F1ZBS is a robust limit switch engineered for industrial automation and machine control applications. This model combines the proven reliability of the 800P series with the flexibility of the 800P-XA contact block, enabling precise limit detection in demanding environments. Heavy-duty construction ensures long service life in harsh conditions, making it a dependable choice for OEMs and system integrators.
Key Features
- Heavy-duty construction rated for industrial environments
- 800P-XA contact block for customizable switching configurations
- Snap-acting mechanism ensures reliable position detection
- Compatible with standard conduit and connector mounting options
- Tested and ready for immediate installation
Technical Specifications
The 800P-1F1ZBS delivers consistent performance across a range of industrial applications:
- Contact configuration: Single-pole contact block (1F)
- Contact type: 800P-XA modular contact block
- Operating temperature range: -18°C to +60°C standard industrial range
- Enclosure rating: NEMA 4X / IP67 (typical for 800P series)
- Contact rating: 10 A at 120/240 VAC nominal
- Mounting: DIN rail and panel mount options
- Switch mechanism: Snap-acting for positive engagement
Typical Applications
- Machine limit detection and travel stops
- Conveyor system position sensing
- Industrial door and gate interlocks
- Elevator and lift position monitoring
- Automated machinery safety circuits
Compatibility & Replacements
Compatible With
- Allen-Bradley 800P series operator heads and bases
- 800P-XA contact block systems
- Standard industrial control circuits (AC/DC)
- NEMA and IEC-compliant enclosures
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. The 800P-1F1ZBS is designed as a direct replacement within the 800P series family when matched with the same contact block configuration.
Works With
- FactoryTalk View and Logix platforms for monitoring
- Standard 24 VDC and 120/240 VAC control circuits
- EtherNet/IP networks via compatible gateway modules
- Safety-rated systems when installed per UL/CSA requirements
