Overview
The Allen-Bradley RC42GF115J is a precision carbon composition resistor engineered for industrial control and electronic applications requiring stable high-resistance values. This 2-watt, 1.1-megohm component combines time-proven hot-molded construction with oxygen-free copper leads, making it ideal for retrofit and repair of legacy industrial equipment where original Allen-Bradley components are specified.
Key Features
- Hot-molded carbon composition element for thermal and electrical stability
- Oxygen-free copper axial leads minimize oxidation and ensure reliable soldering
- ±5% tolerance (J-grade) meets tight specification requirements
- Operating temperature range to 70°C with predictable resistance drift characteristics
- Compliant with MIL-R-39008 military specification standards
Technical Specifications
- Manufacturer: Allen-Bradley
- Part Number: RC42GF115J
- Resistance Value: 1.1 MΩ (1,100,000 ohms)
- Power Rating: 2 watts
- Tolerance: ±5% (J-grade)
- Construction: Hot-molded carbon composition
- Lead Material: Oxygen-free copper, axial terminals
- Max Operating Temperature: 70°C ambient
- Specification: MIL-R-39008 / MIL-R-11A
- Packaging: Individual unit, New in Box
Typical Applications
The RC42GF115J serves critical functions in legacy industrial control systems, including bias resistors in signal conditioning circuits, high-impedance load resistors in analog front-ends, and gate/grid protection networks in power electronics. Common use cases span vintage PLC analog input modules, motor control preamps, sensor interface conditioning, and instrumentation calibration networks.
Compatibility & Replacements
