Overview
The Allen-Bradley 800H-W101 is a standard gray legend plate designed for 30mm 800H push-button control stations. This industrial-duty accessory clearly labels button functions with pre-printed “CLOSE” text, improving operator clarity and panel safety in demanding manufacturing and process control environments. Rated NEMA 4/4X for reliable performance in wet, corrosive, and high-vibration settings.
Key Features
- Pre-printed “CLOSE” text in gray on gray background for clear visibility
- 30mm form factor compatible with 800H push-button series
- NEMA 4/4X enclosure rating for wet and corrosive environments
- Durable plastic construction resists moisture, chemicals, and temperature extremes
- Standard legend plate size fits all 800H-series push buttons seamlessly
Technical Specifications
- Part Number: 800H-W101
- Manufacturer: Allen-Bradley / Rockwell Automation
- Button Size: 30mm
- Legend Text: CLOSE
- Color: Gray (text and background)
- Enclosure Rating: NEMA 4/4X
- Material: Plastic
- Type: Standard Legend Plate
- UPC: 662073638773
Typical Applications
- Motor start/stop and valve control stations
- Process shutdown and emergency circuits
- Pump and compressor on/off panels
- Machine tool and automation control enclosures
- Wastewater and chemical processing plants
- Food processing and packaging lines
Compatibility & Replacements
Compatible With
- Allen-Bradley 800H series 30mm push buttons
- 800H control stations and operator interfaces
- NEMA 4/4X-rated industrial enclosures
- Standard push-button legend plate slots
Replaces / Drop-In Replacement For
- Original equipment 800H-W101 plates on retrofit or maintenance
- Other gray “CLOSE” legend plates for 30mm push buttons (verify fitment)
Works With
- Allen-Bradley 800H push-button control stations
- Rockwell Automation control panel assemblies
- Standard 30mm push-button enclosure cavities
- NEMA 4/4X electrical enclosures
