Overview
The Allen-Bradley 889D-F5NCDM-5 is a Series B DC Micro (M12) quick disconnect cordset engineered for precision industrial connectivity. This Bulletin 889 cordset provides secure connections for proximity sensors, limit switches, photoelectric sensors and other field devices. The 889D-F5NCDM-5 offers a 5-meter cable length and 5-pin connector configuration, making it ideal for flexible sensor and actuator installations in motion control, automation, and control panel applications.
Key Features
- 5-Pin DC Micro (M12) Connector: Available with straight overmolded connectors featuring a choice of materials and jacket colors.
- 5-Meter Cable Length: Provides adequate reach for distributed field device placement without requiring splicing.
- Series B Configuration: Meets industrial-grade durability and environmental standards for factory floor deployment.
- Quick Disconnect (QD) Design: Enables rapid component replacement and system troubleshooting with minimal downtime.
- PVC/PUR Housing: Oil-resistant construction suitable for washdown and exposure to industrial fluids.
- Pre-Terminated Assembly: Factory-assembled cordset eliminates field termination errors and accelerates installation.
Technical Specifications
Verify exact specifications with your documentation before ordering, as some parameters vary by configuration variant:
- Connector Type: DC Micro (M12) quick disconnect, 5-pin
- Cable Length: 5 meters (16.4 feet)
- Conductor Gauge: Typically 22 AWG
- Cable Jacket: PVC or PUR, black, unshielded
- Connector Housing: Molded oil-resistant overmolded design
- Contact Material: Gold over nickel-plated brass
- Coupling Nut: Epoxy-coated zinc
- Series Designation: Series B
- Standard Compliance: DC Micro (M12) industrial standard
Typical Applications
The 889D-F5NCDM-5 cordset is commonly deployed in:
- Proximity and inductive sensor connections in manufacturing cells
- Photoelectric sensor and limit switch installations
- Field device wiring in motion control systems and drives
- Allen-Bradley CompactLogix, ControlLogix, and MicroLogix distributed I/O networks
- Siemens and third-party PLC sensor input modules requiring M12 connectors
- Factory automation, packaging, and material handling equipment
Compatibility & Replacements
Compatible With
- Allen-Bradley CompactLogix and ControlLogix controllers via distributed I/O modules
- Proximity sensors and inductive limit switches with M12 5-pin receptacles
- Photoelectric sensors requiring DC Micro quick disconnect interfaces
- Allen-Bradley 1714, 1715, and allied CANopen/EtherNet/IP field device networks
- Standard DC Micro (M12) female connectors across industrial brands
Replaces / Drop-In Replacement For
The 889D-F5NCDM-5 may directly replace other Allen-Bradley 889D Series cordsets with identical 5-pin M12 DC Micro configurations (such as 889D-F5BC-5 and similar variants). Verify exact connector type and pin assignment before substitution to ensure signal integrity.
Works With
- Allen-Bradley Studio 5000 Logix Designer (sensor device configuration)
- Siemens TIA Portal and S7-1200/1500 with PROFINET I/O modules
- EtherNet/IP and CANopen protocol-based distributed I/O
- Mitsubishi GX Developer and Q-series PLC M12 sensor modules
- Omron CX and NX series controllers with M12 field adapters
