Overview
The Allen-Bradley 800T-XA is a 30mm shallow contact block designed for use with 800T and 800H series pushbuttons in industrial control applications. With its 1 NO / 1 NC contact configuration and 600V AC rating, this non-metallic contact block delivers reliable switching performance in demanding industrial environments. Base-mounted with screw terminal attachment, the 800T-XA provides a cost-effective solution for panel builders, system integrators, and maintenance technicians.
Key Features
- 1 Normally Open (NO) and 1 Normally Closed (NC) contact configuration
- 30mm 800T/800H series compatibility with proven Rockwell design
- 600V AC contact rating with 10A at 230V AC capacity
- Non-metallic base mounting with screw terminal attachment
- NEMA 4/13 Type rated; UL, CSA, CE, CCC, KC, and MARINE certified
- Shallow profile reduces panel depth requirements
Technical Specifications
Typical Applications
The 800T-XA is commonly deployed in:
- Machine tool control circuits and emergency stop systems
- Industrial motor starter and contactor circuits
- Conveyor, pump, and compressor control panels
- Process monitoring and interlock applications
- HVAC and facility automation systems
- OEM equipment requiring 800T/800H pushbutton integration
Compatibility & Replacements
Compatible With
- Allen-Bradley 800T series 30mm pushbuttons
- Allen-Bradley 800H series 30mm pushbuttons
- Industrial control panels and enclosures (NEMA 1, 4, 13, and equivalents)
- Standard panel mounting systems with base-mount requirements
Replaces / Drop-In Replacement For
- Previous generation 800T-XA shallow contact blocks
- Equivalent 30mm pushbutton contact blocks with matching pin configuration
Works With
- Allen-Bradley ControlLogix, CompactLogix, and SLC 500 systems
- Siemens SIMATIC S7 and S5 controllers via standard hardwired circuits
- Mitsubishi FX and Q-series PLCs in hardwired control applications
- Omron CPM and CJ-series controllers
- Standard relay logic and pneumatic control circuits
- 24V DC and 120V AC control circuits (contact block rated independently)
