Overview
The Allen-Bradley 800T-XA /D is a shallow contact block assembly for use with 800T series 30mm push button stations. It is a shallow contact block that provides auxiliary switching functionality in industrial automation applications. The Allen Bradley 800T-XA is a contact block with a voltage rating of 600VAC. This component integrates seamlessly into existing 800T control systems to expand functionality with additional contacts for pilot duty and control circuitry.
Key Features
- Contact Configuration: 1 NO, 1 NC with 10 A contact rating at 230 VAC-15
- 600 VAC Max voltage rating with base mount design
- Used for 800T and 800H series 30mm push button applications
- Standard terminal type for industrial control panels
- Certifications include CSA Listed, CE, and UL Listed
- Compact form factor for space-constrained installations
Technical Specifications
| Manufacturer | Allen-Bradley (Rockwell Automation) |
| Part Number | 800T-XA /D |
| Product Type | Shallow Contact Block |
| Size | 30mm |
| Contact Configuration | 1 Normally Open / 1 Normally Closed |
| Contact Rating | 10A @ 230VAC |
| Voltage Rating | 600VAC Maximum |
| Mounting Style | Base Mount |
| Terminal Type | Screw |
| Series | 800T / Bulletin 800T |
| Weight | 0.05 lbs |
| Certifications | UL Listed, CSA, CE, CCC |
| Condition | New in Box |
Typical Applications
- Industrial control panels and pushbutton stations
- Pilot duty switching for motor starters and contactors
- Emergency stop (E-stop) circuit integration
- Process control signaling and feedback
- Machine tool automation and sequencing
- Factory automation assembly lines
Compatibility & Replacements
Compatible With
- 800T series 30mm push button stations
- 800H series push button assemblies
- Allen-Bradley control systems
- Standard industrial control panel designs
- 600VAC pilot duty control circuits
Replaces / Drop-In Replacement For
- Allen-Bradley 800T-XA (all series)
- Earlier generation 800T shallow contact blocks
- Compatible with other 1NO/1NC 30mm contact block designs rated for similar voltage/current specifications
Works With
- 800T bulletin push button operators and enclosures
- IEC 60947-5-5 compliant control stations
- NEMA Type 4/13 rated assemblies
- Standard screw terminal wiring practices
- DC or AC pilot circuits up to 600VAC
[“800T-XA contact block”, “shallow contact block 30mm”, “Allen-Bradley pilot device”, “600VAC contact block”, “800T series push button”]
