Overview
The Allen-Bradley 800H-FRXT6D4 is a maintained (latching) push button designed for harsh industrial environments. This 30mm device combines a standard mushroom head operator with a push-pull/twist release mechanism, making it ideal for emergency stop stations and manual control circuits where operator feedback and positive engagement are critical.
Key Features
- Maintained Action: Push-pull/twist to release; state remains until manually cleared
- Push-Pull/Twist Release: Prevents accidental operation; requires intentional action to reset
- Red Mushroom Head: High-visibility operator; standard 30.5mm size for ergonomic control
- Non-Illuminated: No lamp required; simplifies wiring and reduces power consumption
- Type 4/4X/13 Rated: Provides robust IP66/IP67 level sealing for indoor or outdoor enclosures
- Standards Compliant: Meets UL, CSA, CE, CUL, KC, and MARINE certifications; 1 NC (normally closed) contact block meets EN ISO 13850 for emergency stop applications
Technical Specifications
- Catalog Number: 800H-FRXT6D4
- Operator Size: 30.5 mm
- Positions: 2-position (push-pull/twist)
- Head Type: Standard mushroom, red plastic
- Contact Configuration: 1 NC (normally closed, latching block; dual-input NCLB)
- Release Mechanism: Push-pull/twist to release
- Mounting Type: Surface-mount (screw terminals)
- Illumination: Non-illuminated
- Protection Rating: Type 4/4X/13 (IP66/IP67 equivalent)
- Operating Temperature: −25 °C to +60 °C (consult Rockwell Automation for sub-freezing moisture conditions)
- Weight: 0.18 lbs (approximately 81 grams)
- Certifications: UL, CSA, CE, CUL, KC, MARINE
- Contact Block Rating: Maximum 2.5 A AC continuous; dual-input latching (NCLB)
Typical Applications
- Emergency stop (E-stop) control stations when paired with monitored safety relays
- Machine start/stop circuits requiring maintained (latching) action
- Manual motor starters and process control stations
- Punch press and material handling equipment control
- Industrial automation systems with modular 800H control stations
- OLED and general-duty industrial control panels
Compatibility & Replacements
Compatible With
- Allen-Bradley Bulletin 800H modular pushbutton enclosures and control stations
- 30 mm push button mounting cavities (standard industrial footprint)
- Rockwell Automation control systems and motor control centers
- Universal industrial automation platforms (Type 4/4X/13 rated enclosures)
- Dual-input monitoring and logic circuits (NCLB contact block design)
Replaces / Drop-In Replacement For
- Verify compatibility with your system integrator before ordering for exact cross-reference information.
Works With
- Allen-Bradley motor control centers and pilot device modules
- Standard screw-terminal wiring and field-installable contact blocks
- Safety relay monitoring circuits (NCLB meets EN ISO 13850)
- General-purpose control logic and soft-start systems
