Overview
The Allen-Bradley 22A-D1P4N104 is a PowerFlex 4 series adjustable frequency AC drive engineered for cost-effective motor speed control in compact, space-saving applications. The 22A-D1P4N104 is a PowerFlex 4 Adjustable Frequency AC Drive from Allen Bradley. This drive is part of the industry-leading PowerFlex family, recognized for reliable performance in OEM and end-user applications.
Key Features
- Operates at 480VAC, 3-Phase with output power of 0.4 kW or 0.5 HP
- 1.4 Amperes output current with IP20 NEMA / Open rated enclosure
- Supports V/Hz control method for consistent speed by maintaining proportionality between frequency and voltage
- Supports torque control implementation
- Compact DIN-rail mountable design with integral 4-digit LED display and fixed digital keypad
- Terminal block connection; no CE-compliant filter configuration
Technical Specifications
- Input Voltage: 480VAC, 3-Phase
- Output Power: 0.4 kW (0.5 HP)
- Output Current: 1.4 Amperes
- Input Voltage Range: 340–528 VAC (per Rockwell Automation technical data)
- Enclosure Rating: IP20 NEMA / Open
- Mounting: DIN-rail or panel mount
- Series: PowerFlex 4, Series A
- Control Modes: V/Hz and torque control
- Communication: RS485 port available
Typical Applications
PowerFlex 4 drives are designed for speed control of applications such as machine tools, fans, pumps and conveyors, and material handling systems. The compact form factor and cost-effective pricing make the 22A-D1P4N104 ideal for fractional-horsepower motor control in retrofit and new installations where space is limited.
Compatibility & Replacements
Compatible With
- Rockwell Automation Studio 5000 (via optional communications modules)
- Allen-Bradley PowerFlex drive family ecosystem
- 140M motor protectors and contactors (Series A rated devices)
- EtherNet/IP and MODBUS protocol support (network options)
- Standard 3-phase induction motors 0.5 HP and below
Replaces / Drop-In Replacement For
- Earlier PowerFlex 4 generation models with same footprint and terminal layout
- Verify exact compatibility with your integrator before ordering, as terminal configurations may vary by vintage.
Works With
- RS485 serial communication for parameter setup and monitoring
- Integral fixed digital keypad for standalone commissioning
- Optional DeviceNet, EtherNet/IP, and PROFIBUS gateway modules
- Rockwell Automation PowerFlex commissioning software
